NXP LS1043A低功耗4核通信处理器

发布时间：2025-02-11 08:54:26 浏览：579

LS1043A处理器概述

　　架构：LS1043A是NXP公司推出的首款四核、64位Arm®架构处理器，属于Layerscape系列。

　　性能：提供超过10 Gbps的性能，适用于小尺寸、低功耗的网络、工业和汽车应用。

　　I/O灵活性：支持无风扇设计，优化了物料清单(BOM)，适用于经济型低层PCB、低成本电源和单时钟设计。

　　低功耗版本：推出了0.9V版本，进一步降低功耗，适用于无线局域网(WLAN)和以太网供电(PoE)系统。

　　封装兼容性：23x23封装选项支持与LS1046A(四核A72处理器)或LS1088A(八核A53处理器)的引脚兼容设计。

　　性能提升：相比双核32位Arm处理器，LS1043A提供了显著的性能提升。

　　集成QUICC Engine®：支持无胶连接的HDLC、TDM或Profibus等传统接口。

　　平台归属：Layerscape处理器是NXP的EdgeVerse™边缘计算平台的一部分。

　　应用场景

　　LS1043A适用于以下领域：

　　网络设备：小型交换机、路由器等。

　　工业自动化：支持Profibus等工业协议的设备。

　　汽车电子：适用于对功耗和性能有较高要求的车载网络系统。

　　物联网(IoT)：作为边缘计算设备的核心处理器。

　　型号：

Part Number	Marketing Description	Package Type	Package Pitch (mm)	Core Type	Operating Frequency [Max] (MHz)	Ambient Operating Temperature (Min to Max) (℃)
LS1023ABE9MQB	Layerscape 64-bit Arm Cortex-A53, Dual-core, 1.2GHz, AEC-Q100 Grade 2, Security enabled, 23x23 pkg	FBGA780	0.8	Arm Cortex-A53	1200	-40 to 105
LS1023ABE9PQB	Layerscape 64-bit Arm Cortex-A53, Dual-core, 1.4GHz, AEC-Q100 Grade 2, Security enabled, 23x23 pkg	FBGA780	0.8	Arm Cortex-A53	1400	-40 to 105
LS1023ACE9MQB	Layerscape 64-bit Arm Cortex-A53, Dual-core, 1.2GHz, AEC-Q100 Grade 3, Security enabled, 23x23 pkg	FBGA780	0.8	Arm Cortex-A53	1200	-40 to 85
LS1023ACE9PQB	Layerscape 64-bit Arm Cortex-A53, Dual-core, 1.4GHz, AEC-Q100 Grade 3, Security enabled, 23x23 pkg	FBGA780	0.8	Arm Cortex-A53	1400	-40 to 85
LS1023ACE9QQB	Layerscape 64-bit Arm Cortex-A53, Dual-core, 1.6GHz, AEC-Q100 Grade 3, Security enabled, 23x23 pkg	FBGA780	0.8	Arm Cortex-A53	1600	-40 to 85
LS1023ASE7KNLB	Layerscape 64-bit Arm Cortex-A53, Dual-core, 1.0GHz, 0 to 105C, Security enabled, 21x21 pkg, Low power	FBGA621	0.8	Arm Cortex-A53	1000
LS1023ASE7KQB	Layerscape 64-bit Arm Cortex-A53, Dual-core, 1.0GHz, 0 to 105C, Security enabled, 21x21 pkg	FBGA621	0.8	Arm Cortex-A53	1000
LS1023ASE7MNLB	Layerscape 64-bit Arm Cortex-A53, Dual-core, 1.2GHz, 0 to 105C, Security enabled, 21x21 pkg, Low power	FBGA621	0.8	Arm Cortex-A53	1200
LS1023ASE7MQB	Layerscape 64-bit Arm Cortex-A53, Dual-core, 1.2GHz, 0 to 105C, Security enabled, 21x21 pkg	FBGA621	0.8	Arm Cortex-A53	1200
LS1023ASE7PQB	Layerscape 64-bit Arm Cortex-A53, Dual-core, 1.4GHz, 0 to 105C, Security enabled, 21x21 pkg	FBGA621	0.8	Arm Cortex-A53	1400
LS1023ASE7QQB	Layerscape 64-bit Arm Cortex-A53, Dual-core, 1.6GHz, 0 to 105C, Security enabled, 21x21 pkg	FBGA621	0.8	Arm Cortex-A53	1600
LS1023ASE8KNLB	Layerscape 64-bit Arm Cortex-A53, Dual-core, 1.0GHz, 0 to 105C, Security enabled, 23x23 pkg, Low power	FBGA780	0.8	Arm Cortex-A53	1000
LS1023ASE8KQB	Layerscape 64-bit Arm Cortex-A53, Dual-core, 1.0GHz, 0 to 105C, Security enabled, 23x23 pkg	FBGA780	0.8	Arm Cortex-A53	1000
LS1023ASE8MNLB	Layerscape 64-bit Arm Cortex-A53, Dual-core, 1.2GHz, 0 to 105C, Security enabled, 23x23 pkg, Low power	FBGA780	0.8	Arm Cortex-A53	1200
LS1023ASE8MQB	Layerscape 64-bit Arm Cortex-A53, Dual-core, 1.2GHz, 0 to 105C, Security enabled, 23x23 pkg	FBGA780	0.8	Arm Cortex-A53	1200
LS1023ASE8PQB	Layerscape 64-bit Arm Cortex-A53, Dual-core, 1.4GHz, 0 to 105C, Security enabled, 23x23 pkg	FBGA780	0.8	Arm Cortex-A53	1400
LS1023ASE8QQB	Layerscape 64-bit Arm Cortex-A53, Dual-core, 1.6GHz, 0 to 105C, Security enabled, 23x23 pkg	FBGA780	0.8	Arm Cortex-A53	1600
LS1023ASN7KNLB	Layerscape 64-bit Arm Cortex-A53, Dual-core, 1.0GHz, 0 to 105C, Security disabled, 21x21 pkg, Low power	FBGA621	0.8	Arm Cortex-A53	1000
LS1023ASN7KQB	Layerscape 64-bit Arm Cortex-A53, Dual-core, 1.0GHz, 0 to 105C, Security disabled, 21x21 pkg	FBGA621	0.8	Arm Cortex-A53	1000
LS1023ASN7MNLB	Layerscape 64-bit Arm Cortex-A53, Dual-core, 1.2GHz, 0 to 105C, Security disabled, 21x21 pkg, Low power	FBGA621	0.8	Arm Cortex-A53	1200	0 to 105
LS1023ASN7MQB	Layerscape 64-bit Arm Cortex-A53, Dual-core, 1.2GHz, 0 to 105C, Security disabled, 21x21 pkg	FBGA621	0.8	Arm Cortex-A53	1200	0 to 105
LS1023ASN7PQB	Layerscape 64-bit Arm Cortex-A53, Dual-core, 1.4GHz, 0 to 105C, Security disabled, 21x21 pkg	FBGA621	0.8	Arm Cortex-A53	1400	0 to 105
LS1023ASN7QQB	Layerscape 64-bit Arm Cortex-A53, Dual-core, 1.6GHz, 0 to 105C, Security disabled, 21x21 pkg	FBGA621	0.8	Arm Cortex-A53	1600	0 to 105
LS1023ASN8KNLB	Layerscape 64-bit Arm Cortex-A53, Dual-core, 1.0GHz, 0 to 105C, Security disabled, 23x23 pkg, Low power	FBGA780	0.8	Arm Cortex-A53	1000	0 to 105
LS1023ASN8KQB	Layerscape 64-bit Arm Cortex-A53, Dual-core, 1.0GHz, 0 to 105C, Security disabled, 23x23 pkg	FBGA780	0.8	Arm Cortex-A53	1000	0 to 105
LS1023ASN8MNLB	Layerscape 64-bit Arm Cortex-A53, Dual-core, 1.2GHz, 0 to 105C, Security disabled, 23x23 pkg, Low power	FBGA780	0.8	Arm Cortex-A53	1200	0 to 105
LS1023ASN8MQB	Layerscape 64-bit Arm Cortex-A53, Dual-core, 1.2GHz, 0 to 105C, Security disabled, 23x23 pkg	FBGA780	0.8	Arm Cortex-A53	1200	0 to 105
LS1023ASN8PQB	Layerscape 64-bit Arm Cortex-A53, Dual-core, 1.4GHz, 0 to 105C, Security disabled, 23x23 pkg	FBGA780	0.8	Arm Cortex-A53	1400	0 to 105
LS1023ASN8QQB	Layerscape 64-bit Arm Cortex-A53, Dual-core, 1.6GHz, 0 to 105C, Security disabled, 23x23 pkg	FBGA780	0.8	Arm Cortex-A53	1600	0 to 105
LS1023AXE7KQB	Layerscape 64-bit Arm Cortex-A53, Dual-core, 1.0GHz, -40 to 105C, Security enabled, 21x21 pkg	FBGA621	0.8	Arm Cortex-A53	1000	-40 to 105
LS1023AXE7MQB	Layerscape 64-bit Arm Cortex-A53, Dual-core, 1.2GHz, -40 to 105C, Security enabled, 21x21 pkg	FBGA621	0.8	Arm Cortex-A53	1200	-40 to 105
LS1023AXE7MQB	Layerscape 64-bit Arm Cortex-A53, Dual-core, 1.2GHz, -40 to 105C, Security enabled, 21x21 pkg	FBGA621	0.8	Arm Cortex-A53	1200	-40 to 105
LS1023AXE7PQB	Layerscape 64-bit Arm Cortex-A53, Dual-core, 1.4GHz, -40 to 105C, Security enabled, 21x21 pkg	FBGA621	0.8	Arm Cortex-A53	1400	-40 to 105
LS1023AXE7QQB	Layerscape 64-bit Arm Cortex-A53, Dual-core, 1.6GHz, -40 to 105C, Security enabled, 21x21 pkg	FBGA621	0.8	Arm Cortex-A53	1600	-40 to 105
LS1023AXE8KQB	Layerscape 64-bit Arm Cortex-A53, Dual-core, 1.0GHz, -40 to 105C, Security enabled, 23x23 pkg	FBGA780	0.8	Arm Cortex-A53	1000	-40 to 105
LS1023AXE8MQB	Layerscape 64-bit Arm Cortex-A53, Dual-core, 1.2GHz, -40 to 105C, Security enabled, 23x23 pkg	FBGA780	0.8	Arm Cortex-A53	1200	-40 to 105
LS1023AXE8PQB	Layerscape 64-bit Arm Cortex-A53, Dual-core, 1.4GHz, -40 to 105C, Security enabled, 23x23 pkg	FBGA780	0.8	Arm Cortex-A53	1400	-40 to 105
LS1023AXE8QQB	Layerscape 64-bit Arm Cortex-A53, Dual-core, 1.6GHz, -40 to 105C, Security enabled, 23x23 pkg	FBGA780	0.8	Arm Cortex-A53	1600	-40 to 105
LS1023AXN7KQB	Layerscape 64-bit Arm Cortex-A53, Dual-core, 1.0GHz, -40 to 105C, Security disabled, 21x21 pkg	FBGA621	0.8	Arm Cortex-A53	1000	-40 to 105
LS1023AXN7MQB	Layerscape 64-bit Arm Cortex-A53, Dual-core, 1.2GHz, -40 to 105C, Security disabled, 21x21 pkg	FBGA621	0.8	Arm Cortex-A53	1200	-40 to 105
LS1023AXN7PQB	Layerscape 64-bit Arm Cortex-A53, Dual-core, 1.4GHz, -40 to 105C, Security disabled, 21x21 pkg	FBGA621	0.8	Arm Cortex-A53	1400	-40 to 105
LS1023AXN7QQB	Layerscape 64-bit Arm Cortex-A53, Dual-core, 1.6GHz, -40 to 105C, Security disabled, 21x21 pkg	FBGA621	0.8	Arm Cortex-A53	1600	-40 to 105
LS1023AXN8KQB	Layerscape 64-bit Arm Cortex-A53, Dual-core, 1.0GHz, -40 to 105C, Security disabled, 23x23 pkg	FBGA780	0.8	Arm Cortex-A53	1000	-40 to 105
LS1023AXN8MQB	Layerscape 64-bit Arm Cortex-A53, Dual-core, 1.2GHz, -40 to 105C, Security disabled, 23x23 pkg	FBGA780	0.8	Arm Cortex-A53	1200	-40 to 105
LS1023AXN8MQB	Layerscape 64-bit Arm Cortex-A53, Dual-core, 1.2GHz, -40 to 105C, Security disabled, 23x23 pkg	FBGA780	0.8	Arm Cortex-A53	1200	-40 to 105
LS1023AXN8PQB	Layerscape 64-bit Arm Cortex-A53, Dual-core, 1.2GHz, -40 to 105C, Security disabled, 23x23 pkg	FBGA780	0.8	Arm Cortex-A53	1400	-40 to 105
LS1023AXN8QQB	Layerscape 64-bit Arm Cortex-A53, Dual-core, 1.2GHz, -40 to 105C, Security disabled, 23x23 pkg	FBGA780	0.8	Arm Cortex-A53	1600	-40 to 105
LS1043ABE9MQB	Layerscape 64-bit Arm Cortex-A53, Quad-core, 1.2GHz, AEC-Q100 Grade 2, Security enabled, 23x23 pkg	FBGA780	0.8	Arm Cortex-A53	1200	-40 to 105
LS1043ABE9PQB	Layerscape 64-bit Arm Cortex-A53, Quad-core, 1.4GHz, AEC-Q100 Grade 2, Security enabled, 23x23 pkg	FBGA780	0.8	Arm Cortex-A53	1400	-40 to 105
LS1043ACE9MQB	Layerscape 64-bit Arm Cortex-A53, Quad-core, 1.2GHz, AEC-Q100 Grade 3, Security enabled, 23x23 pkg	FBGA780	0.8	Arm Cortex-A53	1200	-40 to 85
LS1043ACE9PQB	Layerscape 64-bit Arm Cortex-A53, Quad-core, 1.4GHz, AEC-Q100 Grade 3, Security enabled, 23x23 pkg	FBGA780	0.8	Arm Cortex-A53	1400	-40 to 85
LS1043ACE9QQB	Layerscape 64-bit Arm Cortex-A53, Quad-core, 1.6GHz, AEC-Q100 Grade 3, Security enabled, 23x23 pkg	FBGA780	0.8	Arm Cortex-A53	1600	-40 to 85
LS1043ASE7KNLB	Layerscape 64-bit Arm Cortex-A53, Quad-core, 1.0GHz, 0 to 105C, Security enabled, 21x21 pkg, Low power	FBGA621	0.8	Arm Cortex-A53	1000	0 to 105
LS1043ASE7KQB	Layerscape 64-bit Arm Cortex-A53, Quad-core, 1.0GHz, 0 to 105C, Security enabled, 21x21 pkg	FBGA621	0.8	Arm Cortex-A53	1000	0 to 105
LS1043ASE7KQB	Layerscape 64-bit Arm Cortex-A53, Quad-core, 1.0GHz, 0 to 105C, Security enabled, 21x21 pkg	FBGA621	0.8	Arm Cortex-A53	1000	0 to 105
LS1043ASE7MNLA	Layerscape 64-bit Arm Cortex-A53, Quad-core, 1.2GHz, 0 to 105C, Security enabled, 21x21 pkg, Low power	FBGA621	0.8		1200	-40 to 105
LS1043ASE7MNLB	Layerscape 64-bit Arm Cortex-A53, Quad-core, 1.2GHz, 0 to 105C, Security enabled, 21x21 pkg, Low power	FBGA621	0.8	Arm Cortex-A53	1200	0 to 105
LS1043ASE7MNLB	Layerscape 64-bit Arm Cortex-A53, Quad-core, 1.2GHz, 0 to 105C, Security enabled, 21x21 pkg, Low power	FBGA621	0.8	Arm Cortex-A53	1200	0 to 105
LS1043ASE7MQA	Layerscape 64-bit Arm Cortex-A53, Quad-core, 1.2GHz, 0 to 105C, Security enabled, 21x21 pkg	FBGA621	0.8	Arm Cortex-A53	1200	0 to 105
LS1043ASE7MQB	Layerscape 64-bit Arm Cortex-A53, Quad-core, 1.2GHz, 0 to 105C, Security enabled, 21x21 pkg	FBGA621	0.8	Arm Cortex-A53	1200	0 to 105
LS1043ASE7PQA	Layerscape 64-bit Arm Cortex-A53, Quad-core, 1.4GHz, 0 to 105C, Security enabled, 21x21 pkg	FBGA621	0.8	Arm Cortex-A53	1400	0 to 105
LS1043ASE7PQB	Layerscape 64-bit Arm Cortex-A53, Quad-core, 1.4GHz, 0 to 105C, Security enabled, 21x21 pkg	FBGA621	0.8	Arm Cortex-A53	1400	0 to 105
LS1043ASE7PQB	Layerscape 64-bit Arm Cortex-A53, Quad-core, 1.4GHz, 0 to 105C, Security enabled, 21x21 pkg	FBGA621	0.8	Arm Cortex-A53	1400	0 to 105
LS1043ASE7QQA	Layerscape 64-bit Arm Cortex-A53, Quad-core, 1.6GHz, 0 to 105C, Security enabled, 21x21 pkg	FBGA621	0.8	Arm Cortex-A53	1600	0 to 105
LS1043ASE7QQB	Layerscape 64-bit Arm Cortex-A53, Quad-core, 1.6GHz, 0 to 105C, Security enabled, 21x21 pkg	FBGA621	0.8	Arm Cortex-A53	1600	0 to 105
LS1043ASE7QQB	Layerscape 64-bit Arm Cortex-A53, Quad-core, 1.6GHz, 0 to 105C, Security enabled, 21x21 pkg	FBGA621	0.8	Arm Cortex-A53	1600	0 to 105
LS1043ASE8KNLB	Layerscape 64-bit Arm Cortex-A53, Quad-core, 1.0GHz, 0 to 105C, Security enabled, 23x23 pkg, Low power	FBGA780	0.8	Arm Cortex-A53	1000	0 to 105
LS1043ASE8KQB	Layerscape 64-bit Arm Cortex-A53, Quad-core, 1.0GHz, 0 to 105C, Security enabled, 23x23 pkg	FBGA780	0.8	Arm Cortex-A53	1000	0 to 105
LS1043ASE8MNLA	Layerscape 64-bit Arm Cortex-A53, Quad-core, 1.2GHz, 0 to 105C, Security enabled, 23x23 pkg, Low power	FBGA780	0.8		1200	-40 to 105
LS1043ASE8MNLB	Layerscape 64-bit Arm Cortex-A53, Quad-core, 1.2GHz, 0 to 105C, Security enabled, 23x23 pkg, Low power	FBGA780	0.8	Arm Cortex-A53	1200	0 to 105
LS1043ASE8MQB	Layerscape 64-bit Arm Cortex-A53, Quad-core, 1.2GHz, 0 to 105C, Security enabled, 23x23 pkg	FBGA780	0.8	Arm Cortex-A53	1200	0 to 105
LS1043ASE8MQB	Layerscape 64-bit Arm Cortex-A53, Quad-core, 1.2GHz, 0 to 105C, Security enabled, 23x23 pkg	FBGA780	0.8	Arm Cortex-A53	1200	0 to 105
LS1043ASE8PQB	Layerscape 64-bit Arm Cortex-A53, Quad-core, 1.4GHz, 0 to 105C, Security enabled, 23x23 pkg	FBGA780	0.8	Arm Cortex-A53	1400	0 to 105
LS1043ASE8QQA	Layerscape 64-bit Arm Cortex-A53, Quad-core, 1.6GHz, 0 to 105C, Security enabled, 23x23 pkg	FBGA780	0.8		1600	-40 to 105
LS1043ASE8QQB	Layerscape 64-bit Arm Cortex-A53, Quad-core, 1.6GHz, 0 to 105C, Security enabled, 23x23 pkg	FBGA780	0.8	Arm Cortex-A53	1600	0 to 105
LS1043ASE8QQB	Layerscape 64-bit Arm Cortex-A53, Quad-core, 1.6GHz, 0 to 105C, Security enabled, 23x23 pkg	FBGA780	0.8	Arm Cortex-A53	1600	0 to 105
LS1043ASN7KNLB	Layerscape 64-bit Arm Cortex-A53, Quad-core, 1.0GHz, 0 to 105C, Security disabled, 21x21 pkg, Low power	FBGA621	0.8	Arm Cortex-A53	1000	0 to 105
LS1043ASN7KQA	Layerscape 64-bit Arm Cortex-A53, Quad-core, 1.0GHz, 0 to 105C, Security disabled, 21x21 pkg	FBGA621	0.8	Arm Cortex-A53	1000	0 to 105
LS1043ASN7KQB	Layerscape 64-bit Arm Cortex-A53, Quad-core, 1.0GHz, 0 to 105C, Security disabled, 21x21 pkg	FBGA621	0.8	Arm Cortex-A53	1000	0 to 105
LS1043ASN7MNLB	Layerscape 64-bit Arm Cortex-A53, Quad-core, 1.2GHz, 0 to 105C, Security disabled, 21x21 pkg, Low power	FBGA621	0.8	Arm Cortex-A53	1200	0 to 105
LS1043ASN7MQA	Layerscape 64-bit Arm Cortex-A53, Quad-core, 1.2GHz, 0 to 105C, Security disabled, 21x21 pkg	FBGA621	0.8	Arm Cortex-A53	1200	0 to 105
LS1043ASN7MQB	Layerscape 64-bit Arm Cortex-A53, Quad-core, 1.2GHz, 0 to 105C, Security disabled, 21x21 pkg	FBGA621	0.8	Arm Cortex-A53	1200	0 to 105
LS1043ASN7PQB	Layerscape 64-bit Arm Cortex-A53, Quad-core, 1.4GHz, 0 to 105C, Security disabled, 21x21 pkg	FBGA621	0.8	Arm Cortex-A53	1400	0 to 105
LS1043ASN7PQB	Layerscape 64-bit Arm Cortex-A53, Quad-core, 1.4GHz, 0 to 105C, Security disabled, 21x21 pkg	FBGA621	0.8	Arm Cortex-A53	1400	0 to 105
LS1043ASN7QQB	Layerscape 64-bit Arm Cortex-A53, Quad-core, 1.6GHz, 0 to 105C, Security disabled, 21x21 pkg	FBGA621	0.8	Arm Cortex-A53	1600	0 to 105
LS1043ASN8KNLA	Layerscape 64-bit Arm Cortex-A53, Quad-core, 1.0GHz, 0 to 105C, Security disabled, 23x23 pkg, Low power	FBGA780	0.8		1000	-40 to 105
LS1043ASN8KNLB	Layerscape 64-bit Arm Cortex-A53, Quad-core, 1.0GHz, 0 to 105C, Security disabled, 23x23 pkg, Low power	FBGA780	0.8	Arm Cortex-A53	1000	0 to 105
LS1043ASN8KQB	Layerscape 64-bit Arm Cortex-A53, Quad-core, 1.0GHz, 0 to 105C, Security disabled, 23x23 pkg	FBGA780	0.8	Arm Cortex-A53	1000	0 to 105
LS1043ASN8MNLB	Layerscape 64-bit Arm Cortex-A53, Quad-core, 1.2GHz, 0 to 105C, Security disabled, 23x23 pkg, Low power	FBGA780	0.8	Arm Cortex-A53	1200	0 to 105
LS1043ASN8MNLB	Layerscape 64-bit Arm Cortex-A53, Quad-core, 1.2GHz, 0 to 105C, Security disabled, 23x23 pkg, Low power	FBGA780	0.8	Arm Cortex-A53	1200	0 to 105
LS1043ASN8MQB	Layerscape 64-bit Arm Cortex-A53, Quad-core, 1.2GHz, 0 to 105C, Security disabled, 23x23 pkg	FBGA780	0.8	Arm Cortex-A53	1200	0 to 105
LS1043ASN8PQB	Layerscape 64-bit Arm Cortex-A53, Quad-core, 1.4GHz, 0 to 105C, Security disabled, 23x23 pkg	FBGA780	0.8	Arm Cortex-A53	1400	0 to 105
LS1043ASN8QQA	Layerscape 64-bit Arm Cortex-A53, Quad-core, 1.6GHz, 0 to 105C, Security disabled, 23x23 pkg	FBGA780	0.8		1600	-40 to 105
LS1043ASN8QQB	Layerscape 64-bit Arm Cortex-A53, Quad-core, 1.6GHz, 0 to 105C, Security disabled, 23x23 pkg	FBGA780	0.8	Arm Cortex-A53	1600	0 to 105
LS1043ASN8QQB	Layerscape 64-bit Arm Cortex-A53, Quad-core, 1.6GHz, 0 to 105C, Security disabled, 23x23 pkg	FBGA780	0.8	Arm Cortex-A53	1600	0 to 105
LS1043AXE7KQA	Layerscape 64-bit Arm Cortex-A53, Quad-core, 1.0GHz, -40 to 105C, Security enabled, 21x21 pkg	FBGA621	0.8	Arm Cortex-A53	1000	-40 to 105
LS1043AXE7KQA	Layerscape 64-bit Arm Cortex-A53, Quad-core, 1.0GHz, -40 to 105C, Security enabled, 21x21 pkg	FBGA621	0.8	Arm Cortex-A53	1000	-40 to 105
LS1043AXE7KQB	Layerscape 64-bit Arm Cortex-A53, Quad-core, 1.0GHz, -40 to 105C, Security enabled, 21x21 pkg	FBGA621	0.8	Arm Cortex-A53	1000	-40 to 105
LS1043AXE7KQB	Layerscape 64-bit Arm Cortex-A53, Quad-core, 1.0GHz, -40 to 105C, Security enabled, 21x21 pkg	FBGA621	0.8	Arm Cortex-A53	1000	-40 to 105
LS1043AXE7MQB	Layerscape 64-bit Arm Cortex-A53, Quad-core, 1.2GHz, -40 to 105C, Security enabled, 21x21 pkg	FBGA621	0.8	Arm Cortex-A53	1200	-40 to 105
LS1043AXE7MQB	Layerscape 64-bit Arm Cortex-A53, Quad-core, 1.2GHz, -40 to 105C, Security enabled, 21x21 pkg	FBGA621	0.8	Arm Cortex-A53	1200	-40 to 105
LS1043AXE7PQB	Layerscape 64-bit Arm Cortex-A53, Quad-core, 1.4GHz, -40 to 105C, Security enabled, 21x21 pkg	FBGA621	0.8	Arm Cortex-A53	1400	-40 to 105
LS1043AXE7QQA	Layerscape 64-bit Arm Cortex-A53, Quad-core, 1.6GHz, -40 to 105C, Security enabled, 21x21 pkg	FBGA621	0.8	Arm Cortex-A53	1600	-40 to 105
LS1043AXE7QQB	Layerscape 64-bit Arm Cortex-A53, Quad-core, 1.6GHz, -40 to 105C, Security enabled, 21x21 pkg	FBGA621	0.8	Arm Cortex-A53	1600	-40 to 105
LS1043AXE7QQB	Layerscape 64-bit Arm Cortex-A53, Quad-core, 1.6GHz, -40 to 105C, Security enabled, 21x21 pkg	FBGA621	0.8	Arm Cortex-A53	1600	-40 to 105
LS1043AXE8KQB	Layerscape 64-bit Arm Cortex-A53, Quad-core, 1.0GHz, -40 to 105C, Security enabled, 23x23 pkg	FBGA780	0.8	Arm Cortex-A53	1000	-40 to 105
LS1043AXE8MQB	Layerscape 64-bit Arm Cortex-A53, Quad-core, 1.2GHz, -40 to 105C, Security enabled, 23x23 pkg	FBGA780	0.8	Arm Cortex-A53	1200	-40 to 105
LS1043AXE8MQB	Layerscape 64-bit Arm Cortex-A53, Quad-core, 1.2GHz, -40 to 105C, Security enabled, 23x23 pkg	FBGA780	0.8	Arm Cortex-A53	1200	-40 to 105
LS1043AXE8PQB	Layerscape 64-bit Arm Cortex-A53, Quad-core, 1.4GHz, -40 to 105C, Security enabled, 23x23 pkg	FBGA780	0.8	Arm Cortex-A53	1400	-40 to 105
LS1043AXE8QQA	Layerscape 64-bit Arm Cortex-A53, Quad-core, 1.6GHz, -40 to 105C, Security enabled, 23x23 pkg	FBGA780	0.8		1600	-40 to 105
LS1043AXE8QQB	Layerscape 64-bit Arm Cortex-A53, Quad-core, 1.6GHz, -40 to 105C, Security enabled, 23x23 pkg	FBGA780	0.8	Arm Cortex-A53	1600	-40 to 105
LS1043AXE8QQB	Layerscape 64-bit Arm Cortex-A53, Quad-core, 1.6GHz, -40 to 105C, Security enabled, 23x23 pkg	FBGA780	0.8	Arm Cortex-A53	1600	-40 to 105
LS1043AXN7KQB	Layerscape 64-bit Arm Cortex-A53, Quad-core, 1.0GHz, -40 to 105C, Security disabled, 21x21 pkg	FBGA621	0.8	Arm Cortex-A53	1000	-40 to 105
LS1043AXN7KQB	Layerscape 64-bit Arm Cortex-A53, Quad-core, 1.0GHz, -40 to 105C, Security disabled, 21x21 pkg	FBGA621	0.8	Arm Cortex-A53	1000	-40 to 105
LS1043AXN7MQA	Layerscape 64-bit Arm Cortex-A53, Quad-core, 1.2GHz, -40 to 105C, Security disabled, 21x21 pkg	FBGA621	0.8	Arm Cortex-A53	1200	-40 to 105
LS1043AXN7MQB	Layerscape 64-bit Arm Cortex-A53, Quad-core, 1.2GHz, -40 to 105C, Security disabled, 21x21 pkg	FBGA621	0.8	Arm Cortex-A53	1200	-40 to 105
LS1043AXN7PQA	Layerscape 64-bit Arm Cortex-A53, Quad-core, 1.4GHz, -40 to 105C, Security disabled, 21x21 pkg	FBGA621	0.8	Arm Cortex-A53	1400	-40 to 105
LS1043AXN7PQB	Layerscape 64-bit Arm Cortex-A53, Quad-core, 1.4GHz, -40 to 105C, Security disabled, 21x21 pkg	FBGA621	0.8	Arm Cortex-A53	1400	-40 to 105
LS1043AXN7QQB	Layerscape 64-bit Arm Cortex-A53, Quad-core, 1.6GHz, -40 to 105C, Security disabled, 21x21 pkg	FBGA621	0.8	Arm Cortex-A53	1600	-40 to 105
LS1043AXN8KQB	Layerscape 64-bit Arm Cortex-A53, Quad-core, 1.0GHz, -40 to 105C, Security disabled, 23x23 pkg	FBGA780	0.8	Arm Cortex-A53	1000	-40 to 105
LS1043AXN8MQB	Layerscape 64-bit Arm Cortex-A53, Quad-core, 1.2GHz, -40 to 105C, Security disabled, 23x23 pkg	FBGA780	0.8	Arm Cortex-A53	1200	-40 to 105
LS1043AXN8PQB	Layerscape 64-bit Arm Cortex-A53, Quad-core, 1.4GHz, -40 to 105C, Security disabled, 23x23 pkg	FBGA780	0.8	Arm Cortex-A53	1400	-40 to 105
LS1043AXN8QQA	Layerscape 64-bit Arm Cortex-A53, Quad-core, 1.6GHz, -40 to 105C, Security disabled, 23x23 pkg	FBGA780	0.8		1600	-40 to 105
LS1043AXN8QQB	Layerscape 64-bit Arm Cortex-A53, Quad-core, 1.6GHz, -40 to 105C, Security disabled, 23x23 pkg	FBGA780	0.8	Arm Cortex-A53	1600	-40 to 105

NXP恩智浦是全球领先的半导体公司，拥有包括MCU微控制器在内的全面产品线,专广泛应用于汽车、工业与物联网等领域，立维创展优势代理分销NXP的MCU产品，欢迎了解。
