TI德州仪器高电压比较器
发布时间：2021-07-06 16:56:37 浏览：4126
电压比较器（简称为比较器）的功能模块是相对比较两个电流电压的大小（输出电压的高电平或低电平用作表明两个输入电流电压的大小关系）。电压比较器能够用在集成化运算放大器的组成中，还能够用专用型的集成化电压比较器。
TI德州仪器高电压比较器具备0.9V到36V的高压比较器，响应时间快，性能强。
深圳市立维创展科技有限公司，专注于TI 德州老品牌可推出的新品，并备有备品系列储备，可当天上线。
详情了解TI德州仪器请点击：/brand/57.html
或联系我们的销售工程师： 0755-83050846 QQ ： 3312069749
Part number | Number of channels
(#) | Propagation delay time
(µs) | Vs
(Max)
(V) | Vs
(Min)
(V) | Iq per channel
(Typ)
(mA) | Vos (offset voltage @ 25 C)
(Max)
(mV) | Input bias current (+/-)
(Max)
(nA) | Operating temperature range
(C) | VICR
(Max)
(V) | VICR
(Min)
(V) |
TL331B | 1 | 1 | 36 | 2 | 0.21 | 2.5 | 25 | -40 to 125 | 34.5 | 0 |
TL391B | 1 | 1 | 36 | 2 | 0.21 | 2.5 | 25 | -40 to 125 | 34.5 | 0 |
LM2903B-Q1 | 2 | 1 | 36 | 2 | 0.2 | 2 | 25 | -40 to 125 | 0 | 34.5 |
LM2903B | 2 | 1 | 36 | 2 | 0.2 | 2 | 25 | -40 to 125 | 34.5 | 0 |
LM393B | 2 | 1 | 36 | 2 | 0.2 | 2 | 25 | -40 to 85 | 34 | 0 |
TLV1805-Q1 | 1 | 0.25 | 40 | 3.3 | 0.15 | 4.5 | 0.5 | -40 to 125 | 0 | 0 |
TLV1805 | 1 | 0.25 | 40 | 3.3 | 0.15 | 4.5 | 0.5 | -40 to 125 | 0 | 0 |
TLV1704-SEP | 4 | 0.56 | 36 | 2.2 | 0.055 | 2.5 | 15 | -55 to 125 | 36 | 2.2 |
TLV6710 | 2 | 9.9 | 36 | 1.8 | 0.008 | 2 | 25 | -40 to 125 | 1.7 | 0 |
TLV6713 | 1 | 10 | 36 | 1.8 | 0.008 | 2 | 25 | -40 to 125 | 1.7 | 0 |
TLV1701-Q1 | 1 | 0.46 | 36 | 2.2 | 0.055 | 3.2 | 15 | -40 to 125 | 36 | 2.2 |
TLV1704-Q1 | 4 | 0.56 | 36 | 2.2 | 0.055 | 2.5 | 15 | -40 to 125 | 36 | 2.2 |
TLV1702-Q1 | 2 | 0.56 | 36 | 2.2 | 0.055 | 2.5 | 15 | -40 to 125 | 36 | 2.2 |
TLV1701 | 1 | 0.56 | 36 | 2.2 | 0.055 | 2.5 | 15 | -40 to 125 | 36 | 2.2 |
TLV1704 | 4 | 0.56 | 36 | 2.2 | 0.055 | 2.5 | 15 | -40 to 125 | 36 | 2.2 |
TLV1702 | 2 | 0.56 | 36 | 2.2 | 0.055 | 2.5 | 15 | -40 to 125 | 36 | 2.2 |
TL331-EP | 1 | 0.3 | 36 | 2 | 0.4 | 5 | 250 | -55 to 125 | 34.5 | 0 |
TL331-Q1 | 1 | 1.3 | 36 | 2 | 0.4 | 5 | 250 | -40 to 125,
-40 to 85 | 34.5 | 0 |
LM293-EP | 2 | 1.3 | 36 | 2 | 0.4 | 5 | 50 | -55 to 125 | 34.5 | 0 |
LM2901EP | 4 | 1.3 | 36 | 2 | 0.2 | 7 | 250 | -40 to 85 | 34 | 0 |
LM111QML-SP | 1 | 0.2 | 36 | 5 | 5.1 | 3 | 100 | -55 to 125 | 34 | 0.5 |
TSM102 | 2 | 1.3 | 30 | 3 | 0.2 | 4.5 | 250 | -40 to 85 | 30 | 3 |
TSM102A | 2 | 1.3 | 30 | 3 | 0.2 | 4.5 | 250 | -40 to 85 | 30 | 3 |
LP2901-Q1 | 4 | 8 | 30 | 3 | 0.015 | 5 | 25 | -40 to 85 | 28.5 | 0 |
TSM104W | 2 | 1.3 | 30 | 3 | 0.35 | 5 | 250 | -40 to 105 | 30 | 3 |
TSM104WA | 2 | 1.3 | 30 | 3 | 0.35 | 3 | 250 | -40 to 105 | 30 | 3 |
LM293A | 2 | 1.3 | 36 | 2 | 0.4 | 2 | 50 | -25 to 85 | 34.5 | 0 |
LM2901AV | 4 | 1.3 | 32 | 2 | 0.2 | 2 | 250 | -40 to 125 | 30.5 | 0 |
LM2901V | 4 | 1.3 | 32 | 2 | 0.2 | 7 | 250 | -40 to 125 | 30.5 | 0 |
LM2903V | 2 | 1.3 | 32 | 2 | 0.4 | 7 | 50 | -40 to 125 | 30.5 | 0 |
LM211-Q1 | 1 | 0.115 | 30 | 3.5 | 5.1 | 3 | 100 | -40 to 125 | 28 | 0.5 |
LM2901AV-Q1 | 4 | 1.3 | 32 | 2 | 0.2 | 2 | 250 | -40 to 125 | 30.5 | 0 |
LM2901V-Q1 | 4 | 1.3 | 32 | 2 | 0.2 | 7 | 250 | -40 to 125 | 30.5 | 0 |
LM2901-Q1 | 4 | 1.3 | 30 | 2 | 0.2 | 7 | 250 | -40 to 125 | 28.5 | 0 |
LM239A-EP | 4 | 1.3 | 36 | 2 | 0.2 | 2.5 | 50 | -40 to 125,
-55 to 125 | 34.5 | 0 |
LM239A-Q1 | 4 | 1.3 | 36 | 2 | 0.2 | 2.5 | 50 | -40 to 125 | 34.5 | 0 |
LM139-SP | 4 | 1.3 | 36 | 2 | 0.2 | 2 | 25 | -55 to 125 | 34.5 | 0 |
LM2903-Q1 | 2 | 1.3 | 30 | 2 | 0.4 | 7 | 50 | -40 to 125,
-40 to 150 | 30.5 | 0 |
TL331 | 1 | 1.3 | 36 | 2 | 0.4 | 5 | 250 | -40 to 85,
-40 to 105 | 34.5 | 0 |
LM211-EP | 1 | 0.115 | 30 | 3.5 | 5.1 | 3 | 100 | -40 to 125,
-55 to 125 | 28 | 0.5 |
LM397 | 1 | 0.44 | 30 | 5 | 0.25 | 7 | 250 | -40 to 85 | 28.5 | 0 |
LM139 | 4 | 1.3 | 36 | 2 | 0.2 | 5 | 25 | -55 to 125 | 34.5 | 0 |
LM139A | 4 | 1.3 | 36 | 2 | 0.2 | 2 | 25 | -55 to 125 | 34.5 | 0 |
LM193 | 2 | 1.3 | 36 | 2 | 0.4 | 5 | 25 | -55 to 125 | 34.5 | 0 |
LM193QML-SP | 2 | 0.7 | 36 | 2 | 0.2 | 5 | 100 | -55 to 125 | 34.5 | 0 |
LM119QML-SP | 2 | 0.025 | 36 | 5 | 4 | 4 | 500 | -55 to 125 | 33 | 3 |
LM139AQML-SP | 4 | 0.7 | 36 | 2 | 0.2 | 2 | 100 | -55 to 125 | 34 | 0 |
LM6511 | 1 | 0.18 | 36 | 2.7 | 2.7 | 5 | 130 | -40 to 85 | 34.75 | 0.5 |
LM211 | 1 | 0.115 | 30 | 3.5 | 5.1 | 3 | 100 | -40 to 85,
-40 to 125 | 13.8 | -14.7 |
LM239 | 4 | 1.3 | 36 | 2 | 0.2 | 2 | 250 | -25 to 85 | 28.5 | 0 |
LM239A | 4 | 1.3 | 36 | 2 | 0.2 | 3 | 50 | -25 to 85 | 34.5 | 0 |
LM293 | 2 | 1.3 | 36 | 2 | 0.4 | 5 | 50 | -25 to 85 | 34.5 | 0 |
LM311 | 1 | 0.115 | 30 | 3.5 | 5.1 | 7.5 | 250 | 0 to 70 | 28 | 0.5 |
LM393 | 2 | 1.3 | 36 | 2 | 0.225 | 5 | 50 | 0 to 70 | 34.5 | 0 |
LM393A | 2 | 0.3 | 30 | 4 | 0.2 | 2 | 50 | 0 to 70 | 34.5 | 0 |
LP211 | 1 | 1.2 | 30 | 3.5 | 0.15 | 7.5 | 100 | -25 to 85 | 28.5 | 0.5 |
LP2901 | 4 | 8 | 30 | 3 | 0.015 | 5 | 25 | -40 to 85 | 28.5 | 0 |
LP311 | 1 | 1.2 | 30 | 3.5 | 0.15 | 7.5 | 100 | 0 to 70 | 13.5 | -14.5 |
LM392 | 2 | 1.5 | 32 | 3 | 0.5 | 5 | 250 | 0 to 70 | 32 | 3 |
LM111 | 1 | 0.115 | 30 | 3.5 | 5.1 | 3 | 100 | -55 to 125 | 28 | 0.5 |
LM111-N | 1 | 0.2 | 36 | 5 | 5.1 | 3 | 100 | -55 to 125 | 34 | 0.5 |
LM111JAN | 1 | 0.2 | 36 | 5 | 5.1 | 3 | 100 | -55 to 125 | 34 | 0.5 |
LM111QML | 1 | 0.2 | 36 | 5 | 5.1 | 3 | 100 | -55 to 125 | 34 | 0.5 |
LM119 | 2 | 0.025 | 36 | 5 | 4 | 4 | 500 | -55 to 125 | 33 | 3 |
LM119QML | 2 | 0.025 | 36 | 5 | 4 | 4 | 500 | -55 to 125 | 33 | 3 |
LM139-N | 4 | 0.7 | 36 | 2 | 0.2 | 5 | 300 | -55 to 125 | 34 | 0 |
LM139A-MIL | 4 | 1.3 | 36 | 2 | 0.2 | 2 | 25 | -55 to 125 | 34.5 | 0 |
LM139AQML | 4 | 0.7 | 36 | 2 | 0.2 | 2 | 100 | -55 to 125 | 34 | 0 |
LM139JAN | 4 | 0.7 | 36 | 2 | 0.2 | 5 | 100 | -55 to 125 | 34 | 0 |
LM193-N | 2 | 0.7 | 36 | 2 | 0.2 | 5 | 100 | -55 to 125 | 34.5 | 0 |
LM193JAN | 2 | 0.7 | 36 | 2 | 0.4 | 5 | 100 | -55 to 125 | 34.5 | 0 |
LM193QML | 2 | 0.7 | 36 | 2 | 0.2 | 5 | 100 | -55 to 125 | 34.5 | 0 |
LM239-N | 4 | 1.3 | 36 | 2 | 0.2 | 5 | 250 | -25 to 85 | 34 | 0 |
LM2901 | 4 | 1.3 | 30 | 2 | 0.2 | 7 | 250 | -40 to 125 | 28.5 | 0 |
LM2901-N | 4 | 0.7 | 36 | 2 | 0.2 | 7 | 250 | -40 to 85 | 34 | 0 |
LM2903 | 2 | 1.3 | 30 | 2 | 0.4 | 7 | 50 | -40 to 125 | 28.5 | 0 |
LM2903-N | 2 | 0.7 | 36 | 2 | 0.2 | 7 | 250 | -40 to 85 | 34.5 | 0 |
LM293-N | 2 | 0.7 | 36 | 2 | 0.2 | 5 | 250 | -25 to 85 | 34.5 | 0 |
LM311-N | 1 | 0.2 | 36 | 5 | 5.1 | 7.5 | 250 | 0 to 70 | 34 | 0.5 |
LM319-N | 2 | 0.025 | 36 | 5 | 4 | 8 | 1000 | 0 to 70 | 34 | 2 |
LM339 | 4 | 1.3 | 30 | 2 | 0.2 | 5 | 50 | 0 to 70 | 28.5 | 0 |
LM339-N | 4 | 1.3 | 36 | 2 | 0.2 | 5 | 250 | 0 to 70 | 34 | 0 |
LM339A | 4 | 1.3 | 30 | 2 | 0.2 | 2 | 50 | 0 to 70 | 28.5 | 0 |
LM361 | 1 | 0.14 | 32 | 11 | 13 | 1 | 30000 | 0 to 70 | 23 | 9 |
LM392-N | 2 | 1.5 | 32 | 3 | 0.5 | 5 | 250 | 0 to 70 | 30 | 0 |
LM393-N | 2 | 0.7 | 36 | 2 | 0.2 | 5 | 250 | 0 to 70 | 34.5 | 0 |
LP339 | 4 | 1.3 | 30 | 5 | 0.015 | 5 | 25 | 0 to 70 | 3.5 | 0 |
LP339-N | 4 | 8 | 36 | 2 | 0.015 | 5 | 25 | 0 to 70 | 34 | 0 |
