SONY工业用CMOS图像传感器
发布时间：2021-01-27 17:02:51 浏览：7186
图像传感器在各种类型工业自动化应用中变得越来越受欢迎。完善的CMOS技术正在提供更大的传感器阵列，以提供更大的视线和更快的图像获取，以满足视觉检测系统的要求。与此同时，新的成像构造和新的软件算法增强了辨识效率，增强了系统的成本效益。伴随着现场可编程门阵列(FPGA)密度的增加和成本的降低，这些算法在工厂车间中的应用越来越广泛，这再次促进了图像传感器的普及。虽然传统观点认为机器视觉需要最高分辨率(见表1)，但CMOS元器件的新构架提供了更高的性能指标，而标准CMOS设备则用作工厂车间的越来越多成像和自动化应用。
SONY是一家综合型的高科技公司，从消费、娱乐到工业半导体产品，在各个行业领域处于领先地位。sony半导体产品，特别是ccd传感器，在行业领域中处于领先地位。SONY广泛应用于车辆、工业视觉、安全、手机等公共场合。
深圳市立维创展科技有限公司，独有特色优势而专注地提供SONY CCD图像传感器产品。
详情了解SONY请点击：/brand/61.html
或联系我们的销售工程师：0755-83642657 QQ: 2295048674
Product Information | Resolution | Effective | Image Size | Aspect | Pixel Size | Frame Rate | I/F | Filter | Technology |
|
| Pixels | [Type] | Ratio | V = H [µm] | [frame/s] |
|
| Shutter Type |
IMX455ALK-K/AQK-K | 61.1 M | 9576 x 6388 | 2.7 | 0.126388889 | 3.76 | 21 | SLVS-EC | Monochrome |
|
|
|
|
|
|
|
|
| RGB | Rolling shutter |
IMX492LLJ/LQJ | 47.0 M | 8336 x 5648 | 1.4 | 0.16875 | 2.315 | 24 | MIPI CSI-2 | Monochrome | Rolling Shutter |
|
|
|
|
|
|
| SLVS-EC | RGB |
|
IMX342LLA/LQA | 31.4 M | 6480 x 4860 | APS-C | 0.16875 | 3.45 | 35 | SLVS | Monochrome |
|
|
|
|
|
|
|
| SLVS-EC | RGB | Global shutter |
IMX571BLR/BQR-J | 26.1 M | 6252 x 4176 | 1.8 | 0.126388889 | 3.76 | 48 | SLVS-EC | Monochrome |
|
|
|
|
|
|
|
|
| RGB | Rolling shutter |
IMX530-AAMJ/AAQJ | 24.5 M | 5328 x 4608 | 1.2 | 0.16875 | 2.74 | 106 | SLVS | Monochrome |
|
|
|
|
|
|
|
| SLVS-EC | RGB | Global shutter |
IMX540-AAMJ/AAQJ | 24.5 M | 5328 x 4608 | 1.2 | 0.16875 | 2.74 | 35 | SLVS | Monochrome |
|
|
|
|
|
|
|
| SLVS-EC | RGB | Global shutter |
IMX183CLK-J/CQJ-J | 20.4 M | 5544 x 3694 | 1 | 0.126388889 | 2.4 | 24 | sub LVDS Serial | Monochrome | Rolling Shutter |
|
|
|
|
|
|
|
| RGB |
|
IMX531-AAMJ/AAQJ | 20.3 M | 4512 x 4512 | 1.1 | 0.042361111 | 2.74 | 109 | SLVS | Monochrome |
|
|
|
|
|
|
|
| SLVS-EC | RGB | Global shutter |
IMX541-AAMJ/AAQJ | 20.3 M | 4512 x 4512 | 1.1 | 0.042361111 | 2.74 | 42 | SLVS | Monochrome |
|
|
|
|
|
|
|
| SLVS-EC | RGB | Global shutter |
IMX367LLA/LQA | 19.6 M | 4432 x 4436 | 44289 | 0.042361111 | 3.45 | 43 | SLVS | Monochrome |
|
|
|
|
|
|
|
| SLVS-EC | RGB | Global shutter |
IMX387LLA/LQA | 16.8 M | 5472 x 3084 | 44289 | 0.672916667 | 3.45 | 61 | SLVS | Monochrome |
|
|
|
|
|
|
|
| SLVS-EC | RGB | Global shutter |
IMX532-AAMJ/AAQJ | 16.1 M | 5328 x 3040 | 1.1 | 0.672916667 | 2.74 | 159 | SLVS | Monochrome |
|
|
|
|
|
|
|
| SLVS-EC | RGB | Global shutter |
IMX542-AAMJ/AAQJ | 16.1 M | 5328 x 3040 | 1.1 | 0.672916667 | 2.74 | 52 | SLVS | Monochrome |
|
|
|
|
|
|
|
| SLVS-EC | RGB | Global shutter |
IMX535-AAMJ/AAQJ | 12.4 M | 4128 x 3008 | 1/1.1 | 0.16875 | 2.74 | 184 | SLVS | Monochrome |
|
|
|
|
|
|
|
| SLVS-EC | RGB | Global shutter |
IMX545-AAMJ/AAQJ | 12.4 M | 4128 x 3008 | 1/1.1 | 0.16875 | 2.74 | 68 | SLVS | Monochrome |
|
|
|
|
|
|
|
| SLVS-EC | RGB | Global shutter |
IMX565-AAMJ/AAQJ | 12.4 M | 4128 x 3008 | 1/1.1 | 0.16875 | 2.74 | 42 | MIPI CSI-2 | Monochrome |
|
|
|
|
|
|
|
|
| RGB | Global shutter |
IMX226CLJ | 12.4 M | 4072 x 3046 | 1/1.7 | 0.16875 | 1.85 | 40 | sub LVDS Serial | Monochrome |
|
|
|
|
|
|
|
|
|
| Rolling Shutter |
IMX304LLR/LQR | 12.3 M | 4112 x 3008 | 1.1 | 0.16875 | 3.45 | 23 | sub LVDS Serial | Monochrome |
|
|
|
|
|
|
|
|
| RGB | Global shutter |
IMX253LLR/LQR | 12.3 M | 4112 x 3008 | 1.1 | 0.16875 | 3.45 | 68 | sub LVDS Serial | Monochrome |
|
|
|
|
|
|
|
|
| RGB | Global shutter |
IMX305LQR | 8.9 M | 4112 x 2176 | 1 | 0.714583333 | 3.45 | 63 | sub LVDS Serial | RGB |
|
|
|
|
|
|
|
|
|
| Global shutter |
IMX267LLR/LQR | 8.9 M | 4112 x 2176 | 1 | 0.714583333 | 3.45 | 32 | sub LVDS Serial | Monochrome |
|
|
|
|
|
|
|
|
| RGB | Global shutter |
IMX255LLR/LQR | 8.9 M | 4112 x 2176 | 1 | 0.714583333 | 3.45 | 93 | sub LVDS Serial | Monochrome |
|
|
|
|
|
|
|
|
| RGB | Global shutter |
IMX334LLR/LQR | 8.4 M | 3864 x 2180 | 1/1.8 | 0.672916667 | 2 | 60 | MIPI CSI-2 | Monochrome |
|
|
|
|
|
|
|
|
| RGB | Rolling shutter |
IMX536-AAMJ/AAQJ | 8.1 M | 2856 x 2848 | 44230 | 0.042361111 | 2.74 | 194 | SLVS | Monochrome |
|
|
|
|
|
|
|
| SLVS-EC | RGB | Global shutter |
IMX546-AAMJ/AAQJ | 8.1 M | 2856 x 2848 | 44230 | 0.042361111 | 2.74 | 91 | SLVS | Monochrome |
|
|
|
|
|
|
|
| SLVS-EC | RGB | Global shutter |
IMX566-AAMJ/AAQJ | 8.1 M | 2856 x 2848 | 44230 | 0.042361111 | 2.74 | 62 | MIPI CSI-2 | Monochrome |
|
|
|
|
|
|
|
|
| RGB | Global shutter |
IMX428LLJ/LQJ | 7.1 M | 3216 x 2208 | 1.1 | 0.674305556 | 4.5 | 51 | SLVS | Monochrome |
|
|
|
|
|
|
|
| SLVS-EC | RGB | Global shutter |
IMX420LLJ/LQJ | 7.1 M | 3216 x 2208 | 1.1 | 0.674305556 | 4.5 | 207 | SLVS | Monochrome |
|
|
|
|
|
|
|
| SLVS-EC | RGB | Global shutter |
IMX178LLJ | 6.4 M | 3096 x 2080 | 1/1.8 | 0.126388889 | 2.4 | 60 | sub LVDS Serial | Monochrome |
|
|
|
|
|
|
|
|
|
| Rolling Shutter |
IMX335LLN/LQN | 5.1 M | 2616 x 1964 | 1/2.8 | 0.16875 | 2 | 60 | MIPI CSI-2 | Monochrome |
|
|
|
|
|
|
|
|
| RGB | Rolling Shutter |
IMX537-AAMJ/AAQJ | 5.1 M | 2472 x 2064 | 1/1.8 | 0.211111111 | 2.74 | 259 | SLVS | Monochrome |
|
|
|
|
|
|
|
| SLVS-EC | RGB | Global shutter |
IMX547-AAMJ/AAQJ | 5.1 M | 2472 x 2064 | 1/1.8 | 0.211111111 | 2.74 | 122 | SLVS | Monochrome |
|
|
|
|
|
|
|
| SLVS-EC | RGB | Global shutter |
IMX548-AAMJ/AAQJ | 5.1 M | 2472 x 2064 | 1/1.8 | 0.211111111 | 2.74 | 114 | SLVS | Monochrome |
|
|
|
|
|
|
|
|
| RGB | Global shutter |
IMX567-AAMJ/AAQJ | 5.1 M | 2472 x 2064 | 1/1.8 | 0.211111111 | 2.74 | 96 | MIPI CSI-2 | Monochrome |
|
|
|
|
|
|
|
|
| RGB | Global shutter |
IMX568-AAMJ/AAQJ | 5.1 M | 2472 x 2064 | 1/1.8 | 0.211111111 | 2.74 | 96 | MIPI CSI-2 | Monochrome |
|
|
|
|
|
|
|
|
| RGB | Global shutter |
IMX250LLR/LQR | 5.0 M | 2464 x 2056 | 44230 | 0.211111111 | 3.45 | 163 | sub LVDS Serial | Monochrome |
|
|
|
|
|
|
|
|
| RGB | Global shutter |
IMX264LLR/LQR | 5.0 M | 2464 x 2056 | 44230 | 0.211111111 | 3.45 | 35 | sub LVDS Serial | Monochrome |
|
|
|
|
|
|
|
|
| RGB | Global shutter |
IMX265LLR/LQR | 3.1 M | 2064 x 1544 | 1/1.8 | 0.16875 | 3.45 | 55 | sub LVDS Serial | Monochrome |
|
|
|
|
|
|
|
|
| RGB | Global shutter |
IMX252LLR/LQR | 3.1 M | 2064 x 1544 | 1/1.8 | 0.16875 | 3.45 | 216 | sub LVDS Serial | Monochrome |
|
|
|
|
|
|
|
|
| RGB | Global shutter |
IMX437LQJ | 2.8 M | 1944 x 1472 | 44230 | 0.211111111 | 4.5 | 231 | SLVS | RGB |
|
|
|
|
|
|
|
| SLVS-EC |
| Global shutter |
IMX429LLJ/LQJ | 2.8 M | 1944 x 1472 | 44230 | 0.211111111 | 4.5 | 96 | SLVS | Monochrome |
|
|
|
|
|
|
|
| SLVS-EC | RGB | Global shutter |
IMX421LLJ/LQJ | 2.8 M | 1944 x 1472 | 44230 | 0.211111111 | 4.5 | 409 | SLVS | Monochrome |
|
|
|
|
|
|
|
| SLVS-EC | RGB | Global shutter |
IMX392LLR/LQR | 2.3 M | 1936 x 1216 | 1/2.3 | 0.673611111 | 3.45 | 201 | sub LVDS Serial | Monochrome |
|
|
|
|
|
|
|
|
| RGB | Global shutter |
IMX174LLJ/LQJ | 2.3 M | 1936 x 1216 | 1/1.2 | 0.673611111 | 5.86 | 164 | sub LVDS Serial | Monochrome |
|
|
|
|
|
|
|
|
| RGB | Global shutter |
IMX302LQJ | 2.3 M | 1936 x 1216 | 1/1.2 | 0.673611111 | 5.86 | 64 | sub LVDS Serial | RGB |
|
|
|
|
|
|
|
|
|
| Global shutter |
IMX249LLJ/LQJ | 2.3 M | 1936 x 1216 | 1/1.2 | 0.673611111 | 5.86 | 30 | sub LVDS Serial | Monochrome |
|
|
|
|
|
|
|
|
| RGB | Global shutter |
IMX290LLR | 2.1 M | 1945 x 1097 | 1/2.8 | 0.672916667 | 2.9 | 120 | CMOS Parallel | Monochrome |
|
|
|
|
|
|
|
| sub LVDS Serial |
| Rolling Shutter |
|
|
|
|
|
|
| MIPI CSI-2 |
|
|
IMX430LLJ/LQJ | 2.0 M | 1632 x 1248 | 1/1.7 | 0.16875 | 4.5 | 132 | SLVS | Monochrome |
|
|
|
|
|
|
|
| SLVS-EC | RGB | Global shutter |
IMX422LLJ/LQJ | 2.0 M | 1632 x 1248 | 1/1.7 | 0.16875 | 4.5 | 477 | SLVS | Monochrome |
|
|
|
|
|
|
|
| SLVS-EC | RGB | Global shutter |
IMX432LLJ/LQJ | 1.7 M | 1608 x 1104 | 1.1 | 0.674305556 | 9 | 98 | SLVS | Monochrome |
|
|
|
|
|
|
|
| SLVS-EC | RGB | Global shutter |
IMX425LLJ/LQJ | 1.7 M | 1608 x 1104 | 1.1 | 0.674305556 | 9 | 662 | SLVS | Monochrome |
|
|
|
|
|
|
|
| SLVS-EC | RGB | Global shutter |
IMX296LLR/LQR | 1.5 M | 1456 x 1088 | 1/2.9 | 0.16875 | 3.45 | 60 | MIPI CSI-2 | Monochrome |
|
|
|
|
|
|
|
|
| RGB | Global shutter |
IMX273LLR/LQR | 1.5 M | 1456 x 1088 | 1/2.9 | 0.16875 | 3.45 | 276 | sub LVDS Serial | Monochrome |
|
|
|
|
|
|
|
|
| RGB | Global shutter |
IMX433LLJ/LQJ | 0.5 M | 816 x 624 | 1/1.7 | 0.16875 | 9 | 243 | SLVS | Monochrome |
|
|
|
|
|
|
|
| SLVS-EC | RGB | Global shutter |
IMX426LLJ/LQJ | 0.5 M | 816 x 624 | 1/1.7 | 0.16875 | 9 | 1594 | SLVS | Monochrome |
|
|
|
|
|
|
|
| SLVS-EC | RGB | Global shutter |
IMX297LLR/LQR | 0.4 M | 728 x 544 | 1/2.9 | 0.16875 | 6.9 | 120 | MIPI CSI-2 | Monochrome |
|
|
|
|
|
|
|
|
| RGB | Global shutter |
IMX287LLR/LQR | 0.4 M | 728 x 544 | 1/2.9 | 0.16875 | 6.9 | 523 | sub LVDS Serial | Monochrome |
|
|
|
|
|
|
|
|
| RGB | Global shutter |
IMX397CLN | 0.3 M | 656 x 496 | 1/6.4 | 0.16875 | 3.45 | 240 | MIPI CSI-2 | Monochrome |
|
|
|
|
|
|
|
|
|
| Global shutter |
IMX250MZR/MYR | 5.0 M | 2464 x 2056 | 44230 | 0.211111111 | 3.45 | 163 | sub LVDS Serial | (Polarization) |
|
|
|
|
|
|
|
|
| Monochrome | Global shutter |
|
|
|
|
|
|
|
| RGB |
|
IMX253MZR/MYR | 12.3 M | 4112 x 3008 | 1.1 | 0.16875 | 3.45 | 68 | sub LVDS Serial | (Polarization) |
|
|
|
|
|
|
|
|
| Monochrome | Global shutter |
|
|
|
|
|
|
|
| RGB |
|
IMX264MZR/MYR | 5.0 M | 2464 x 2056 | 44230 | 0.211111111 | 3.45 | 35 | sub LVDS Serial | (Polarization) |
|
|
|
|
|
|
|
|
| Monochrome | Global shutter |
|
|
|
|
|
|
|
| RGB |
|
