Renesas瑞萨MCU微控制器RL78/G22

发布时间：2024-05-14 09:31:07 浏览：1440

　　Renesas MCU微控制器RL78/G22具有以下特点：

　　1. 低功耗：在CPU工作时的电流消耗为37.5μA/MHz，在STOP模式下为200nA。

　　2. 丰富的电容触摸通道。

　　3. 完备的16-48引脚封装和32KB-64KB闪存，展开了新一代RL78通用微控制器的产品线。

　　4. 最大工作频率为32MHz，广泛的工作电压范围为1.6V-5.5V。

　　5. 增强的模拟和安全功能以及SNOOZE模式可编程控制器可大幅降低间歇工作的功耗。

　　6. 提供丰富的开发环境，包括评估板(Fast Prototyping Board)和智能配置器(Smart Configurator)。

　　7. 兼容现有的RL78系列，适用于家电、消费类电子产品到工业设备的广泛用途。

　　具体技术参数包括：

　　- CPU型号：RL78核心，最高32MHz

　　- 工作电压范围：1.6V至5.5V

　　- 封装类型：16引脚至48引脚

　　- 闪存容量：程序闪存：32-64KB，SRAM 4KB，数据闪存2KB

　　- 工作温度范围：可达105°C

　　- 增强型电容式感应单元(CTSU2L)

　　- 定时器：8路16位定时器、1路看门狗定时器、1路32位间隔定时器

　　- PWM输出：7路PWM输出

　　- 模拟功能：10路10位A/D转换器

　　- 片上振荡器频率(MHz)：高速：最高32MHz，中速：最高4MHz，低速：32.768kHz

　　- 贪睡模式排序器

　　- 事件链路控制器

　　- 其他功能：RTC、上电复位、低电压检测

　　- 封装类型：SSOP、LQFP、HWQFN、WFLGA

产品型号：

Product ID	程序存储器（KB）	内存（KB）	温度范围	数据闪存（KB）	I/O 端口	模数转换器	产品尺寸（mm）
R7F102G4C3CNP#AA0	32	4	-40 to 105°C	2	12	10-bit/8-bit x 3-ch	3 x 3 x 0.8
R7F102G4C3CNP#BA0	32	4	-40 to 105°C	2	12	10-bit/8-bit x 3-ch	3 x 3 x 0.8
R7F102G4C3CNP#HA0	32	4	-40 to 105°C	2	12	10-bit/8-bit x 3-ch	3 x 3 x 0.8
R7F102G4C2DNP#AA0	32	4	-40 to 85°C	2	12	10-bit/8-bit x 3-ch	3 x 3 x 0.8
R7F102G4C2DNP#BA0	32	4	-40 to 85°C	2	12	10-bit/8-bit x 3-ch	3 x 3 x 0.8
R7F102G4C2DNP#HA0	32	4	-40 to 85°C	2	12	10-bit/8-bit x 3-ch	3 x 3 x 0.8
R7F102G4E3CNP#AA0	64	4	-40 to 105°C	2	12	10-bit/8-bit x 3-ch	3 x 3 x 0.8
R7F102G4E3CNP#BA0	64	4	-40 to 105°C	2	12	10-bit/8-bit x 3-ch	3 x 3 x 0.8
R7F102G4E3CNP#HA0	64	4	-40 to 105°C	2	12	10-bit/8-bit x 3-ch	3 x 3 x 0.8
R7F102G4E2DNP#AA0	64	4	-40 to 85°C	2	12	10-bit/8-bit x 3-ch	3 x 3 x 0.8
R7F102G4E2DNP#BA0	64	4	-40 to 85°C	2	12	10-bit/8-bit x 3-ch	3 x 3 x 0.8
R7F102G4E2DNP#HA0	64	4	-40 to 85°C	2	12	10-bit/8-bit x 3-ch	3 x 3 x 0.8
R7F102G6C3CSP#CA0	32	4	-40 to 105°C	2	16	10-bit/8-bit x 6-ch	4 x 6 x 1.45
R7F102G6C3CSP#HA0	32	4	-40 to 105°C	2	16	10-bit/8-bit x 6-ch	4 x 6 x 1.45
R7F102G6C2DSP#CA0	32	4	-40 to 85°C	2	16	10-bit/8-bit x 6-ch	4 x 6 x 1.45
R7F102G6C2DSP#HA0	32	4	-40 to 85°C	2	16	10-bit/8-bit x 6-ch	4 x 6 x 1.45
R7F102G6E3CSP#CA0	64	4	-40 to 105°C	2	16	10-bit/8-bit x 6-ch	4 x 6 x 1.45
R7F102G6E3CSP#HA0	64	4	-40 to 105°C	2	16	10-bit/8-bit x 6-ch	4 x 6 x 1.45
R7F102G6E2DSP#CA0	64	4	-40 to 85°C	2	16	10-bit/8-bit x 6-ch	4 x 6 x 1.45
R7F102G6E2DSP#HA0	64	4	-40 to 85°C	2	16	10-bit/8-bit x 6-ch	4 x 6 x 1.45
R7F102G7C3CNP#AA0	32	4	-40 to 105°C	2	20	10-bit/8-bit x 6-ch	4 x 4 x 0.8
R7F102G7C3CNP#BA0	32	4	-40 to 105°C	2	20	10-bit/8-bit x 6-ch	4 x 4 x 0.8
R7F102G7C3CNP#HA0	32	4	-40 to 105°C	2	20	10-bit/8-bit x 6-ch	4 x 4 x 0.8
R7F102G7C2DNP#AA0	32	4	-40 to 85°C	2	20	10-bit/8-bit x 6-ch	4 x 4 x 0.8
R7F102G7C2DNP#BA0	32	4	-40 to 85°C	2	20	10-bit/8-bit x 6-ch	4 x 4 x 0.8
R7F102G7C2DNP#HA0	32	4	-40 to 85°C	2	20	10-bit/8-bit x 6-ch	4 x 4 x 0.8
R7F102G7E3CNP#AA0	64	4	-40 to 105°C	2	20	10-bit/8-bit x 6-ch	4 x 4 x 0.8
R7F102G7E3CNP#BA0	64	4	-40 to 105°C	2	20	10-bit/8-bit x 6-ch	4 x 4 x 0.8
R7F102G7E3CNP#HA0	64	4	-40 to 105°C	2	20	10-bit/8-bit x 6-ch	4 x 4 x 0.8
R7F102G7E2DNP#AA0	64	4	-40 to 85°C	2	20	10-bit/8-bit x 6-ch	4 x 4 x 0.8
R7F102G7E2DNP#BA0	64	4	-40 to 85°C	2	20	10-bit/8-bit x 6-ch	4 x 4 x 0.8
R7F102G7E2DNP#HA0	64	4	-40 to 85°C	2	20	10-bit/8-bit x 6-ch	4 x 4 x 0.8
R7F102G8C3CLA#AC0	32	4	-40 to 105°C	2	21	10-bit/8-bit x 6-ch	3 x 3 x 0.76
R7F102G8C3CLA#BC0	32	4	-40 to 105°C	2	21	10-bit/8-bit x 6-ch	3 x 3 x 0.76
R7F102G8C3CLA#HC0	32	4	-40 to 105°C	2	21	10-bit/8-bit x 6-ch	3 x 3 x 0.76
R7F102G8C2DLA#AC0	32	4	-40 to 85°C	2	21	10-bit/8-bit x 6-ch	3 x 3 x 0.76
R7F102G8C2DLA#BC0	32	4	-40 to 85°C	2	21	10-bit/8-bit x 6-ch	3 x 3 x 0.76
R7F102G8C2DLA#HC0	32	4	-40 to 85°C	2	21	10-bit/8-bit x 6-ch	3 x 3 x 0.76
R7F102G8E3CLA#AC0	64	4	-40 to 105°C	2	21	10-bit/8-bit x 6-ch	3 x 3 x 0.76
R7F102G8E3CLA#BC0	64	4	-40 to 105°C	2	21	10-bit/8-bit x 6-ch	3 x 3 x 0.76
R7F102G8E3CLA#HC0	64	4	-40 to 105°C	2	21	10-bit/8-bit x 6-ch	3 x 3 x 0.76
R7F102G8E2DLA#AC0	64	4	-40 to 85°C	2	21	10-bit/8-bit x 6-ch	3 x 3 x 0.76
R7F102G8E2DLA#BC0	64	4	-40 to 85°C	2	21	10-bit/8-bit x 6-ch	3 x 3 x 0.76
R7F102G8E2DLA#HC0	64	4	-40 to 85°C	2	21	10-bit/8-bit x 6-ch	3 x 3 x 0.76
R7F102GAC3CSP#AA0	32	4	-40 to 105°C	2	26	10-bit/8-bit x 8-ch	10 x 6 x 1.4
R7F102GAC3CSP#BA0	32	4	-40 to 105°C	2	26	10-bit/8-bit x 8-ch	10 x 6 x 1.4
R7F102GAC3CSP#HA0	32	4	-40 to 105°C	2	26	10-bit/8-bit x 8-ch	10 x 6 x 1.4
R7F102GAC2DSP#AA0	32	4	-40 to 85°C	2	26	10-bit/8-bit x 8-ch	10 x 6 x 1.4
R7F102GAC2DSP#BA0	32	4	-40 to 85°C	2	26	10-bit/8-bit x 8-ch	10 x 6 x 1.4
R7F102GAC2DSP#HA0	32	4	-40 to 85°C	2	26	10-bit/8-bit x 8-ch	10 x 6 x 1.4
R7F102GAE3CSP#AA0	64	4	-40 to 105°C	2	26	10-bit/8-bit x 8-ch	10 x 6 x 1.4
R7F102GAE3CSP#BA0	64	4	-40 to 105°C	2	26	10-bit/8-bit x 8-ch	10 x 6 x 1.4
R7F102GAE3CSP#HA0	64	4	-40 to 105°C	2	26	10-bit/8-bit x 8-ch	10 x 6 x 1.4
R7F102GAE2DSP#AA0	64	4	-40 to 85°C	2	26	10-bit/8-bit x 8-ch	10 x 6 x 1.4
R7F102GAE2DSP#BA0	64	4	-40 to 85°C	2	26	10-bit/8-bit x 8-ch	10 x 6 x 1.4
R7F102GAE2DSP#HA0	64	4	-40 to 85°C	2	26	10-bit/8-bit x 8-ch	10 x 6 x 1.4
R7F102GBC3CNP#AA0	32	4	-40 to 105°C	2	28	10-bit/8-bit x 8-ch	5 x 5 x 0.8
R7F102GBC3CNP#BA0	32	4	-40 to 105°C	2	28	10-bit/8-bit x 8-ch	5 x 5 x 0.8
R7F102GBC3CNP#HA0	32	4	-40 to 105°C	2	28	10-bit/8-bit x 8-ch	5 x 5 x 0.8
R7F102GBC2DNP#AA0	32	4	-40 to 85°C	2	28	10-bit/8-bit x 8-ch	5 x 5 x 0.8
R7F102GBC2DNP#BA0	32	4	-40 to 85°C	2	28	10-bit/8-bit x 8-ch	5 x 5 x 0.8
R7F102GBC2DNP#HA0	32	4	-40 to 85°C	2	28	10-bit/8-bit x 8-ch	5 x 5 x 0.8
R7F102GBE3CNP#AA0	64	4	-40 to 105°C	2	28	10-bit/8-bit x 8-ch	5 x 5 x 0.8
R7F102GBE3CNP#BA0	64	4	-40 to 105°C	2	28	10-bit/8-bit x 8-ch	5 x 5 x 0.8
R7F102GBE3CNP#HA0	64	4	-40 to 105°C	2	28	10-bit/8-bit x 8-ch	5 x 5 x 0.8
R7F102GBE2DNP#AA0	64	4	-40 to 85°C	2	28	10-bit/8-bit x 8-ch	5 x 5 x 0.8
R7F102GBE2DNP#BA0	64	4	-40 to 85°C	2	28	10-bit/8-bit x 8-ch	5 x 5 x 0.8
R7F102GBE2DNP#HA0	64	4	-40 to 85°C	2	28	10-bit/8-bit x 8-ch	5 x 5 x 0.8
R7F102GBC3CFP#AA0	32	4	-40 to 105°C	2	28	10-bit/8-bit x 8-ch	7 x 7 x 1.7
R7F102GBC3CFP#BA0	32	4	-40 to 105°C	2	28	10-bit/8-bit x 8-ch	7 x 7 x 1.7
R7F102GBC3CFP#HA0	32	4	-40 to 105°C	2	28	10-bit/8-bit x 8-ch	7 x 7 x 1.7
R7F102GBC2DFP#AA0	32	4	-40 to 85°C	2	28	10-bit/8-bit x 8-ch	7 x 7 x 1.7
R7F102GBC2DFP#BA0	32	4	-40 to 85°C	2	28	10-bit/8-bit x 8-ch	7 x 7 x 1.7
R7F102GBC2DFP#HA0	32	4	-40 to 85°C	2	28	10-bit/8-bit x 8-ch	7 x 7 x 1.7
R7F102GBE3CFP#AA0	64	4	-40 to 105°C	2	28	10-bit/8-bit x 8-ch	7 x 7 x 1.7
R7F102GBE3CFP#BA0	64	4	-40 to 105°C	2	28	10-bit/8-bit x 8-ch	7 x 7 x 1.7
R7F102GBE3CFP#HA0	64	4	-40 to 105°C	2	28	10-bit/8-bit x 8-ch	7 x 7 x 1.7
R7F102GBE2DFP#AA0	64	4	-40 to 85°C	2	28	10-bit/8-bit x 8-ch	7 x 7 x 1.7
R7F102GBE2DFP#BA0	64	4	-40 to 85°C	2	28	10-bit/8-bit x 8-ch	7 x 7 x 1.7
R7F102GBE2DFP#HA0	64	4	-40 to 85°C	2	28	10-bit/8-bit x 8-ch	7 x 7 x 1.7
R7F102GCC3CLA#BC0	32	4	-40 to 105°C	2	32	10-bit/8-bit x 8-ch	4 x 4 x 0.76
R7F102GCC3CLA#AC0	32	4	-40 to 105°C	2	32	10-bit/8-bit x 8-ch	4 x 4 x 0.76
R7F102GCC3CLA#HC0	32	4	-40 to 105°C	2	32	10-bit/8-bit x 8-ch	4 x 4 x 0.76
R7F102GCC2DLA#BC0	32	4	-40 to 85°C	2	32	10-bit/8-bit x 8-ch	4 x 4 x 0.76
R7F102GCC2DLA#AC0	32	4	-40 to 85°C	2	32	10-bit/8-bit x 8-ch	4 x 4 x 0.76
R7F102GCC2DLA#HC0	32	4	-40 to 85°C	2	32	10-bit/8-bit x 8-ch	4 x 4 x 0.76
R7F102GCE3CLA#BC0	64	4	-40 to 105°C	2	32	10-bit/8-bit x 8-ch	4 x 4 x 0.76
R7F102GCE3CLA#AC0	64	4	-40 to 105°C	2	32	10-bit/8-bit x 8-ch	4 x 4 x 0.76
R7F102GCE3CLA#HC0	64	4	-40 to 105°C	2	32	10-bit/8-bit x 8-ch	4 x 4 x 0.76
R7F102GCE2DLA#BC0	64	4	-40 to 85°C	2	32	10-bit/8-bit x 8-ch	4 x 4 x 0.76
R7F102GCE2DLA#AC0	64	4	-40 to 85°C	2	32	10-bit/8-bit x 8-ch	4 x 4 x 0.76
R7F102GCE2DLA#HC0	64	4	-40 to 85°C	2	32	10-bit/8-bit x 8-ch	4 x 4 x 0.76
R7F102GEC3CNP#AA0	32	4	-40 to 105°C	2	36	10-bit/8-bit x 9-ch	6 x 6 x 0.8
R7F102GEC3CNP#BA0	32	4	-40 to 105°C	2	36	10-bit/8-bit x 9-ch	6 x 6 x 0.8
R7F102GEC3CNP#HA0	32	4	-40 to 105°C	2	36	10-bit/8-bit x 9-ch	6 x 6 x 0.8
R7F102GEC2DNP#AA0	32	4	-40 to 85°C	2	36	10-bit/8-bit x 9-ch	6 x 6 x 0.8
R7F102GEC2DNP#BA0	32	4	-40 to 85°C	2	36	10-bit/8-bit x 9-ch	6 x 6 x 0.8
R7F102GEC2DNP#HA0	32	4	-40 to 85°C	2	36	10-bit/8-bit x 9-ch	6 x 6 x 0.8
R7F102GEE3CNP#AA0	64	4	-40 to 105°C	2	36	10-bit/8-bit x 9-ch	6 x 6 x 0.8
R7F102GEE3CNP#BA0	64	4	-40 to 105°C	2	36	10-bit/8-bit x 9-ch	6 x 6 x 0.8
R7F102GEE3CNP#HA0	64	4	-40 to 105°C	2	36	10-bit/8-bit x 9-ch	6 x 6 x 0.8
R7F102GEE2DNP#AA0	64	4	-40 to 85°C	2	36	10-bit/8-bit x 9-ch	6 x 6 x 0.8
R7F102GEE2DNP#BA0	64	4	-40 to 85°C	2	36	10-bit/8-bit x 9-ch	6 x 6 x 0.8
R7F102GEE2DNP#HA0	64	4	-40 to 85°C	2	36	10-bit/8-bit x 9-ch	6 x 6 x 0.8
R7F102GFC3CFP#AA0	32	4	-40 to 105°C	2	40	10-bit/8-bit x 10-ch	10 x 10 x 1.6
R7F102GFC3CFP#BA0	32	4	-40 to 105°C	2	40	10-bit/8-bit x 10-ch	10 x 10 x 1.6
R7F102GFC3CFP#HA0	32	4	-40 to 105°C	2	40	10-bit/8-bit x 10-ch	10 x 10 x 1.6
R7F102GFC2DFP#AA0	32	4	-40 to 85°C	2	40	10-bit/8-bit x 10-ch	10 x 10 x 1.6
R7F102GFC2DFP#BA0	32	4	-40 to 85°C	2	40	10-bit/8-bit x 10-ch	10 x 10 x 1.6
R7F102GFC2DFP#HA0	32	4	-40 to 85°C	2	40	10-bit/8-bit x 10-ch	10 x 10 x 1.6
R7F102GFE3CFP#AA0	64	4	-40 to 105°C	2	40	10-bit/8-bit x 10-ch	10 x 10 x 1.6
R7F102GFE3CFP#BA0	64	4	-40 to 105°C	2	40	10-bit/8-bit x 10-ch	10 x 10 x 1.6
R7F102GFE3CFP#HA0	64	4	-40 to 105°C	2	40	10-bit/8-bit x 10-ch	10 x 10 x 1.6
R7F102GFE2DFP#AA0	64	4	-40 to 85°C	2	40	10-bit/8-bit x 10-ch	10 x 10 x 1.6
R7F102GFE2DFP#BA0	64	4	-40 to 85°C	2	40	10-bit/8-bit x 10-ch	10 x 10 x 1.6
R7F102GFE2DFP#HA0	64	4	-40 to 85°C	2	40	10-bit/8-bit x 10-ch	10 x 10 x 1.6
R7F102GGC3CFB#AA0	32	4	-40 to 105°C	2	44	10-bit/8-bit x 10-ch	7 x 7 x 1.7
R7F102GGC3CFB#BA0	32	4	-40 to 105°C	2	44	10-bit/8-bit x 10-ch	7 x 7 x 1.7
R7F102GGC3CFB#HA0	32	4	-40 to 105°C	2	44	10-bit/8-bit x 10-ch	7 x 7 x 1.7
R7F102GGC2DFB#AA0	32	4	-40 to 85°C	2	44	10-bit/8-bit x 10-ch	7 x 7 x 1.7
R7F102GGC2DFB#BA0	32	4	-40 to 85°C	2	44	10-bit/8-bit x 10-ch	7 x 7 x 1.7
R7F102GGC2DFB#HA0	32	4	-40 to 85°C	2	44	10-bit/8-bit x 10-ch	7 x 7 x 1.7
R7F102GGE3CFB#AA0	64	4	-40 to 105°C	2	44	10-bit/8-bit x 10-ch	7 x 7 x 1.7
R7F102GGE3CFB#BA0	64	4	-40 to 105°C	2	44	10-bit/8-bit x 10-ch	7 x 7 x 1.7
R7F102GGE3CFB#HA0	64	4	-40 to 105°C	2	44	10-bit/8-bit x 10-ch	7 x 7 x 1.7
R7F102GGE2DFB#AA0	64	4	-40 to 85°C	2	44	10-bit/8-bit x 10-ch	7 x 7 x 1.7
R7F102GGE2DFB#BA0	64	4	-40 to 85°C	2	44	10-bit/8-bit x 10-ch	7 x 7 x 1.7
R7F102GGE2DFB#HA0	64	4	-40 to 85°C	2	44	10-bit/8-bit x 10-ch	7 x 7 x 1.7
R7F102GGC3CNP#AA0	32	4	-40 to 105°C	2	44	10-bit/8-bit x 10-ch	7 x 7 x 0.8
R7F102GGC3CNP#BA0	32	4	-40 to 105°C	2	44	10-bit/8-bit x 10-ch	7 x 7 x 0.8
R7F102GGC3CNP#HA0	32	4	-40 to 105°C	2	44	10-bit/8-bit x 10-ch	7 x 7 x 0.8
R7F102GGC2DNP#AA0	32	4	-40 to 85°C	2	44	10-bit/8-bit x 10-ch	7 x 7 x 0.8
R7F102GGC2DNP#BA0	32	4	-40 to 85°C	2	44	10-bit/8-bit x 10-ch	7 x 7 x 0.8
R7F102GGC2DNP#HA0	32	4	-40 to 85°C	2	44	10-bit/8-bit x 10-ch	7 x 7 x 0.8
R7F102GGE3CNP#AA0	64	4	-40 to 105°C	2	44	10-bit/8-bit x 10-ch	7 x 7 x 0.8
R7F102GGE3CNP#BA0	64	4	-40 to 105°C	2	44	10-bit/8-bit x 10-ch	7 x 7 x 0.8
R7F102GGE3CNP#HA0	64	4	-40 to 105°C	2	44	10-bit/8-bit x 10-ch	7 x 7 x 0.8
R7F102GGE2DNP#AA0	64	4	-40 to 85°C	2	44	10-bit/8-bit x 10-ch	7 x 7 x 0.8
R7F102GGE2DNP#BA0	64	4	-40 to 85°C	2	44	10-bit/8-bit x 10-ch	7 x 7 x 0.8
R7F102GGE2DNP#HA0	64	4	-40 to 85°C	2	44	10-bit/8-bit x 10-ch	7 x 7 x 0.8
