Renesas微控制器和微处理器RL78 低功耗 8 位和 16 位 MCU

发布时间：2021-03-22 17:10:47 浏览：1147

Renesas微控制器和微处理器RL788/16位微控制器（MCU）进一步提高了电源效率，具备行业技术领先的低功耗性能指标。正常情况下工作时功能损耗为45.5μA/MHz，时钟工作时功能损耗为0.57μA/MHz。内嵌高精度（±1%）高速片上振荡器、可重写100万次的后台管理操作数据闪存、温度传感器和多电源接口端口等功能有利于减少系统生产成本和重量。

深圳市立维创展科技有限公司，优势代理分销Renesas产品线，部分系列常备现货。

详情了解Renesas请点击：/brand/59.html

或联系我们的销售工程师：0755-83642657 QQ: 2295048674

器件数量: 30	Bit Size	CPU	Program Memory (KB)	Data Flash (KB)	RAM (KB)	Lead Count (#)	Supply Voltage (V)
	16	RL78	24, 32, 48, 64, 96, 128, 256, 384, 512	8	2, 3, 4, 6, 8, 16, 20, 24	48, 64, 80, 100, 128	2.7 - 5.5
RL78/D1A
	16	RL78	8, 16, 24, 32, 48, 64	4	0.5, 1, 1.5, 2, 3, 4	20, 30, 32, 48, 64	1.8 - 5.5, 2.7 - 5.5
RL78/F12
	16	RL78	16, 32, 48, 64, 96, 128	4	1, 2, 3, 4, 6, 8	20, 30, 32, 48, 64, 80	2.7 - 5.5
RL78/F13
	16	RL78	48, 64, 96, 128, 192, 256	4, 8	4, 6, 8, 10, 16, 20	30, 32, 48, 64, 80, 100	2.7 - 5.5
RL78/F14
	16	RL78	128, 192, 256, 384, 512	8, 16	10, 16, 20, 26, 32	48, 64, 80, 100, 144	2.7 - 5.5
RL78/F15
	8	RL78	1, 2, 4	0	0.5, 0.25, 0.125	10, 16	2 - 5.5
RL78/G10
	16	RL78	16	2	1.5	10, 16, 20, 24, 25	1.6 - 5.5
RL78/G11
	16	RL78	2, 4, 8, 12, 16	0, 2	0.5, 0.25, 0.75, 1, 1.5, 2	20, 24, 30	1.8 - 5.5, 2.4 - 5.5
RL78/G12
	16	RL78	16, 32, 48, 64, 96, 128, 192, 256, 384, 512	0, 4, 8	2 ~ 32	20, 24, 25, 30, 32, 36, 40, 44, 48, 52, 64, 80, 100, 128	1.6 - 5.5, 2.4 - 5.5
RL78/G13
	16	RL78	8, 384, 512	8	24, 32	44, 48, 64, 100	1.6 - 5.5, 2.4 - 5.5
RL78/G13A
	16	RL78	16, 32, 48, 64, 96, 128, 192, 256, 384, 512	4, 8	2.5 ~ 48	30, 32, 36, 40, 44, 48, 52, 64, 80, 100	1.6 - 5.5
RL78/G14
	16	RL78	16, 32, 48, 64	4	2, 3, 4	25, 32, 48, 64	1.6 - 3.6, 2.4 - 3.6
RL78/G1A
	16	RL78	32	2	5.5	32, 48	2.4 - 5.5
RL78/G1C
	16	RL78	128, 192, 256	8	12, 16, 20	48	1.6 - 3.6
RL78/G1D
	16	RL78	32, 64	4	5.5	24, 32, 36, 48, 64	1.6 - 5.5
RL78/G1F
	16	RL78	8, 16	0	1.5	30, 32, 44	2.7 - 5.5
RL78/G1G
	16	RL78	256, 384, 512	8	24, 32, 48	64	1.8 - 3.6
RL78/G1H
	8	RL78	8	0	1	20	2 - 5.5
RL78/G1M
	8	RL78	8	0	1	20	2 - 5.5
RL78/G1N
	16	RL78	2, 16	2	1.5	24, 32	2.7 - 3.6
RL78/G1P
	16	RL78	64, 96, 128	4	5.5, 8	48, 64, 80	1.8 - 5.5, 2.4 - 5.5
RL78/H1D
	16	RL78	32, 64	4	2, 4	20, 30, 38	2.7 - 5.5
RL78/I1A
	16	RL78	64, 128	0	6, 8	80, 100	1.9 - 5.5
RL78/I1B
	16	RL78	64, 128, 256, 512	2	6, 8, 16, 32	64, 80, 100	1.6 - 5.5, 1.7 - 5.5
RL78/I1C
	16	RL78	8, 16, 32	2	0.7, 2, 3	20, 24, 30, 32, 48	1.6 - 3.6
RL78/I1D
	16	RL78	32	4	8	32, 36	2.4 - 5.5
RL78/I1E
	16	RL78	8, 16, 32	2	1, 1.5	32, 44, 48, 52, 64	1.6 - 5.5
RL78/L12
	16	RL78	16, 32, 48, 64, 96, 128	4	1, 1.5, 2, 4, 6, 8	64, 80	1.6 - 5.5
RL78/L13
	16	RL78	48, 64, 96, 128	8	5.5	80, 100	1.8 - 3.6
RL78/L1A
	16	RL78	64, 96, 128, 192, 256	8	8, 10, 12, 16	80, 85, 100	1.6 - 3.6
RL78/L1C
