IR HiRel线性稳压器（LDO）
发布时间：2021-03-10 17:06:38 浏览：3004
IR HiRel线性稳压器（LDO）是一种易于使用的电源办理计划，输出电压巩固，静态电流低，输入电压宽，杂音低，封装小。
IR HiRel为产业和汽车使用供应种种低压差分线性调治器(LDO)。通过使用非常小的外部元件来调治巩固的输出电压，能够供应种种负载，包含收发器、微掌握器、传感器和有源天线。这些产物具有多种功能，包含超低静态电流、宽输入电压局限、低噪声、集成电流检验和护卫功能。这些产物使用种种封装，包含无铅封装，可用于EPS、变速箱、车身掌握模块、HVAC、仪表板、ADAS、远程消息处分、CAV和产业使用。
使用平台
电动出行
电机掌握
数据处分
主动化
汽车通用模块
动力总成
身材与便当
有源天线
安全使用
深圳市立维创展科技有限公司，优势渠道供货IR高可靠性系列产品，欢迎各界前来咨询。
详情了解IR HiRel，请点击：http : //www.ldteq.com/public/brand/65.html
或联系我们的销售工程师： 0755- 83642657 QQ： 2295048674
*详情了解更多型号请联系我们的销售工程师。
Product | Operating Voltage min [V] | Operating Voltage max [V] | Output Current max. | Output Voltage Type | Accuracy [%] | Regulator Type | Dropout Voltage | Quiescent Current | Operating Temperature min [°C] | Operating Temperature max [°C] |
TLS850C2TE V33 | 3 | 40 | 500 | 3.3 V | 2 | High Performance |
| 20µA | -40 | 150 |
TLS850C2TE V50 | 3 | 40 | 500 | 5.0 V | 2 | High Performance |
|
| -40 | 150 |
TLE42764DV | 4.5 | 40 | 400 mA | adj. | 2 | General Purpose | 250 mV | 100 µA | -40 | 150 |
TLS205B0EJ V50 | 2.3 | 20 | 500 mA | 5.0 V | 2.5 | Post Regulator | 350 mV | 30 µA | -40 | 125 |
TLF4949SJ | 5.5 | 28 | 100 mA | 5.0 V | 2 | General Purpose | 500 mV | 180 µA | -40 | 125 |
TLE4476D | 4.5
5.7 | 42
42 | 250 mA | 3.3 V | 4
4 | Application Specific - 24V | 1200 mV | 300 µA | -40 | 150 |
TLS820F0EL V33 | 3 | 40 | 200 mA | 3.3 V | 2 | High Performance | 80 mV | 40 µA | -40 | 150 |
TLF80511TF V33 | 3.3 | 45 | 400 mA | 3.3 V | 2 | High Performance | 130 mV | 38 µA | -40 | 150 |
TLE4295G V50 | 5.5 | 45 | 30 mA | 5.0 V | 4 | Linear | 250 mV | 120 µA | -40 | 150 |
TLE4269GM | 5.5 | 45 | 100 mA | 5.0 V | 2 | General Purpose | 250 mV | 240 µA | -40 | 150 |
TLS208D1EJV33 | 2.7 | 18 | 800 mA | 3.3 V | 2 | Post Regulator | 900 mV | 90 µA | -40 | 150 |
TLS202B1MBV33 | 2.7 | 18 | 150 mA | 3.3 V | 3 | Post Regulator | 290 mV | 50 µA | -40 | 150 |
TLE4263-2ES | 5.5 | 45 | 150 mA | 5.0 V | 2 | General Purpose | 350 mV | 900 µA | -40 | 150 |
TLS850F2TA V50 | 3 | 40 | 500 mA | 5.0 V | 2 | High Performance | 70 mV | 40 µA | -40 | 150 |
TLS810D1LD V50 | 2.75 | 42 | 100 mA | 5.0 V | 2 | High Performance | 200 mV | 9.0 µA | -40 | 150 |
TLS102B0MB | 4 | 40 | 20 mA | adj. | 0.1 | Trackers | 120 mV | 40 µA | -40 | 150 |
TLS850D0TE V50 | 3 | 40 | 500 mA | 5.0 V | 2 | High Performance | 70 mV | 40 µA | -40 | 150 |
TLE4267G | 5.5 | 40 | 400 mA | 5.0 V | 2 | General Purpose | 300 mV | 1300 µA | -40 | 150 |
TLE4279G | 5.5 | 45 | 100 mA | 5.0 V | 2 | General Purpose | 250 mV | 210 µA | -40 | 150 |
TLS115B0LD | 4 | 40 | 150 mA | adj. | 0.1 | Trackers | 250 mV | 50 µA | -40 | 150 |
TLE4276GV | 4.5 | 40 | 400 mA | adj. | 4 | General Purpose | 250 mV | 100 µA | -40 | 150 |
TLS205B0EJ V33 | 2.3 | 20 | 500 mA | 3.3 V | 2.5 | Post Regulator | 320 mV | 30 µA | -40 | 125 |
TLE7274-2D | 5.5 | 45 | 300 mA | 5.0 V | 2 | General Purpose | 250 mV | 20 µA | -40 | 150 |
TLE4276G V50 | 5.5 | 40 | 400 mA | 5.0 V | 4 | General Purpose | 250 mV | 100 µA | -40 | 150 |
TLS805B1LDV | 2.75 | 42 | 50 mA | adj. | 2 | High Performance | 100 mV | 5.0 µA | -40 | 150 |
TLE4270-2G | 6 | 42 | 550 mA | 5.0 V | 2 | General Purpose | 350 mV | 1000 µA | -40 | 150 |
TLE42994E V33 | 4.4 | 45 | 150 mA | 3.3 V | 2 | General Purpose | n/a | 65 µA | -40 | 150 |
TLE4264-2G | 5.5 | 45 | 100 mA | 5.0 V | 3 | General Purpose | 220 mV | 40 µA | -40 | 150 |
TLE42694GM | 5.5 | 45 | 100 mA | 5.0 V | 2 | General Purpose | 250 mV | 210 µA | -40 | 150 |
