Hirth3230风冷二冲程发动机

发布于:2024-02-28 17:14:39

品牌名称:Hirth Engines

重要参数:

· 65马力

· 空气冷却

· 2冲程

· 终极功率重量比

· 适用于轻型航空,气垫船,陀螺仪或直升机


  • 产品详情
TYPE:Two cylinder two stroke (inline)
DISPLACEMENT:625 cm3(38,1 in3
STROKE:69 mm (2,72 in)
BORE:76 mm (2,99 in)
MAX.PERFORMANCE:40,4  kW(55  HP)at 5500  rpm
According  to  DIN  70020
MAX.TORQUE:72Nm(52,8  ft.Ib) at  5000  rpm
CARBURATION:2x slide carburetor (Dell   Orto)
or fuel injecton
FUEL MIXTURE:      Mixture 1:50, 2-stroke-oil,
fuel min. 95 octane (RON)
Mixture 1:80-100 with BLUEMAX
2-stroke-oil, fuel min. 95 octane
 WEIGHT:31 kg (68,4 lb)
  LENGTH:377 mm (14.84 in)
  WIDTH:587 mm (23.11 in)
  HEIGHT:383 mm (15.07 in)
 STARTING DEVICE: Recoil starter
 RUNNING DIRECTION: Counter-clockwise,  view  to  output  shaft
 COOLING: Fan cooling
 IGNITION SYSTEM: CDI



OPTIONS:

Dual ignition

Fuel injection

Belt reduction G 27 (1:1,8/1:2,0)

Gear box G 50 (1:2,16/1:2,29/1:2,59/1:3,16/1:3,65)

Electric starter

Separate lubrication
