Lattice CPLD复杂可编程逻辑器件LCMXO2280C-3TN144I

产品详情

MachXO系列：

MachXO经过优化，可满足传统上由cpld和低容量fpga解决的应用需求:粘合逻辑、总线桥接、总线接口、上电控制和控制逻辑。这些器件在单个芯片上汇集了CPLD和FPGA器件的最佳特性。

MachXO系列选型指南

Device	LCMXO256	LCMXO640	LCMXO1200	LCMXO2280
LUTs	256	640	1200	2280
Dist.RAM (Kbits	2.0	6.1	6.4	7.7
EBR SRAM (Kbits	0	0	9.2	27.6
Number of EBR SRAM Blocks (9 Kbits	0	0	1	3
Voc Voltage	1.2/1.8/2.5/3.3V	1.2/1.8/2.5/3.3 V	1.2/1.8/2.5/3.3V	1.2/1.8/2.5/3.3V
Number of PLLs	0	0	1	2
Max.I/0	78	159	211	271
Packages
100-pin TQFP (14x14 mm	78	74	73	73
144-pin TQFP (20x20 mm)		113	113	113
100-ball csBGA (8x8 mm)	78	74
132-ball csBGA (8x8 mm		101	101	101
256-ball caBGA (14x14 mm		159	211	211
256-ball ftBGA (17x17 mm)		159	211	211
324-ball ftBGA (19x19 mm)				271

订购信息：

Part Number	LUTs	Supply Voltage	l/Os	Grade	Package	Pins	Temp
LCMXO256C-3T1001	256	1.8V/2.5V/3.3V	78	-3	TOFP	100	IND
LCMXO256C-4T1001	256	1.8V/2.5V/3.3 V	78	-4	TQFP	100	IND
LCMXO256C-3M100	256	1.8V/2.5V/3.3V	78	-3	CSBGA	100	IND
LCMXO256C-4M100	256	1.8V/2.5V/3.3V	78	-4	CsBGA	100	IND
LCMXO640C-3T1001	640	1.8V/2.5V/3.3V	74	-3	TQFP	100	IND
LCMXO640C-4T1001	640	1.8V/2.5V/3.3V	74	-4	TQFP	100	IND
LCMXO640C-3M100	640	1.8V/2.5V/3.3V	74	-3	CSBGA	100	IND
LCMXO640C-4M100	640	1.8V/2.5V/3.3V	74	-4	CsBGA	100	IND
LCMXO640C-3T1441	640	1.8V/2.5V/3.3 V	113	-3	TQFP	144	IND
LCMXO640C-4T1441	640	1.8V/2.5V/3.3 V	113	-4	TQFP	144	IND
LCMXO640C-3M132	640	1.8V/2.5V/3.3V	101	-3	CSBGA	132	IND
LCMXO640C-4M132	640	1.8V/2.5V/3.3V	101	-4	CsBGA	132	IND
LCMXO640C-38256I	640	1.8V/2.5V/3.3V	159	-3	caBGA	256	IND
LCMXO640C-48256I	640	1.8V/2.5V/3.3V	159	-4	caBGA	256	IND
LCMX0640C-3FT256	640	1.8V/2.5V/3.3V	159	-3	ftBGA	256	ND
LCMXO640C-4FT256	640	1.8V/2.5V/3.3V	159	-4	ftBGA	256	IND
LCMXO1200C-3T1001	1200	1.8V/2.5V/3.3V	73	-3	TOFP	100	IND
LCMXO1200C-4T1001	1200	1.8V/2.5V/3.3 V	73	-4	TQFP	100	IND
LCMXO1200C-3T144I	1200	1.8V/2.5V/3.3V	113	-3	TQFP	144	IND
LCMXO1200C-4T1441	1200	1.8V/2.5V/3.3 V	113	-4	TQFP	144	IND
LCMXO1200C-3M132	1200	1.8V/2.5V/3.3V	101	-3	CSBGA	132	IND
LCMXO1200C-4M132	1200	1.8V/2.5V/3.3 V	101	-4	CSBGA	132	IND
LCMXO1200C-3B256I	1200	1.8V/2.5V/3.3V	211	-3	caBGA	256	IND

Part Number	LUTs	Supply Voltage	l/Os	Grade	Package	Pins	Temp
LCMXO1200C-4B256I	1200	1.8V/2.5V/3.3V	211	-4	caBGA	256	IND
LCMXO1200C-3FT256	1200	1.8V/2.5V/3.3V	211	3	ftBGA	256	IND
LCMXO1200C-4FT256I	1200	1.8V/2.5V/3.3V	211	-4	ftBGA	256	IND
LCMXO2280C-3T100	2280	1.8V/2.5V/3.3V	73	3	TQFP	100	IND
LCMXO2280C-4T100	2280	1.8V/2.5V/3.3V	73	-4	TQFP	100	IND
LCMXO2280C-3T1441	2280	1.8V/2.5V/3.3V	113	-3	TQFP	144	IND
LCMXO2280C-4T1441	2280	1.8V/2.5V/3.3V	113	-4	TQFP	144	IND
LCMXO2280C-3M1321	2280	1.8V/2.5V/3.3V	101	-3	CsBGA	132	IND
LCMXO2280C-4M1321	2280	1.8V/2.5V/3.3V	101	-4	csBGA	132	IND
LCMXO2280C-38256I	2280	1.8V/2.5V/3.3V	211	3	caBGA	256	IND
LCMXO2280C-48256I	2280	1.8V/2.5V/3.3V	211	-4	caBGA	256	IND
LCMXO2280C-3FT256I	2280	1.8V/2.5V/3.3V	211	3	ftBGA	256	IND
LCMXO2280C-4FT2561	2280	1.8V/2.5v/3.3V	211	4	ftBGA	256	IND
LCMXO2280C-3FT324I	2280	1.8V/2.5V/3.3V	271	3	ftBGA	324	IND
LCMXO2280C-4FT324I	2280	1.8V/2.5V/3.3V	271	-4	ftBGA	324	IND
LCMXO256E-3T100I	256	1.2V	78	3	TOFP	100	IND
LCMXO256E-4T100I	256	1.2 V	78	-4	TQFP	100	IND
LCMXO256E-3M100I	256	1.2V	78	3	csBGA	100	IND
LCMXO256E-4M100I	256	1.2 V	78	4	csBGA	100	IND
LCMXO640E-3T100I	640	1.2 V	74	3	TOFP	100	IND
LCMXO640E-4T100	640	1.2V	74	-4	TQFP	100	IND
LCMXO640E-3M100I	640	1.2 V	74	3	csBGA	100	IND
LCMXO640E-4M100I	640	1.2V	74	-4	csBGA	100	IND
LCMXO640E-3T144I	640	1.2 V	113	3	TQFP	144	IND
LCMXO640E-4T144I	640	1.2 V	113	4	TQFP	144	IND
LCMXO640E-3M1321	640	1.2V	101	-3	csBGA	132	IND
LCMXO640E-4M1321	640	1.2V	101	-4	csBGA	132	IND
LCMXO640E-3B256I	640	1.2 V	159	3	caBGA	256	IND
LCMXO640E-4B256I	640	1.2V	159	-4	caBGA	256	IND
LCMXO640E-3FT256I	640	1.2V	159	3	ftBGA	256	IND
LCMXO640E-4FT256I	640	1.2 V	159	4	ftBGA	256	IND
LCMXO1200E-3T100I	1200	1.2V	73	-3	TQFP	100	IND
LCMXO1200E-4T100I	1200	1.2V	73	-4	TOFP	100	IND
LCMXO1200E-3T144I	1200	1.2 V	113	-3	TQFP	144	IND
LCMXO1200E-4T144I	1200	1.2V	113	-4	TQFP	144	IND
LCMXO1200E-3M13.21	1200	1.2 V	101	3	csBGA	132	IND
LCMXO1200E-4M13.21	1200	1.2 V	101	-4	csBGA	132	IND
LCMXO1200E-3B256I	1200	1.2V	211	3	caBGA	256	IND
LCMXO1200E-4B256I	1200	1.2 V	211	-4	caBGA	256	IND
LCMXO1200E-3FT256I	1200	1.2V	211	-3	ftBGA	256	IND
LCMXO1200E-4FT256	1200	1.2 V	211	-4	ftBGA	256	IND
LCMXO2280E-3T100I	2280	1.2 V	73	-3	TQFP	100	IND
LCMXO2280E-4T100I	2280	1.2V	73	-4	TQFP	100	IND
LCMXO2280E-3T1441	2280	1.2 V	113	3	TQFP	144	IND
LCMXO2280E-4T1441	2280	1.2 V	113	-4	TQFP	144	IND
LCMXO2280E-3M13.21	2280	1.2 V	101	3	csBGA	132	IND
LCMXO2280E-4M13.21	2280	1.2V	101	-4	csBGA	132	IND
LCMXO2280E-3B256I	2280	1.2 V	211	3	caBGA	256	IND

Part Number	LUTs	Supply Voltage	l/Os	Grade	Package	Pins	Temp
LCMXO2280E-4B2561	2280	1.2V	211	4	caBGA	256	IND
LCMXO2280E-3FT256	2280	1.2V	211	3	ftBGA	256	IND
LCMXO2280E-4FT256	2280	1.2V	211	4	ftBGA	256	IND
LCMXO2280E-3FT324	2280	1.2V	271	3	ftBGA	324	IND
LCMXO2280E-4FT324	2280	1.2V	271	4	ftBGA	324	IND

Part Number	LUTs	Supply Voltage	l/Os	Grade	Package	Pin	Temp.
LCMXO256C-3TN100I	256	1.8V/2.5V/3.3V	78	-3	Lead-Free TQFP	100	IND
LCMXO256C-4TN100I	256	1.8V/2.5V/3.3V	78	-4	Lead-Free TQFP	100	IND
LCMXO256C-3MN100I	256	1.8V/2.5V/3.3V	78	3	ead-Free csBGA	100	IND
LCMXO256C-4MN100I	256	1.8V/2.5V/3.3V	78	-4	ead-Free csBGA	100	IND
LCMXO640C-3TN100I	640	1.8V/2.5V/3.3 V	74	-3	Lead-Free TOFP	100	IND
LCMXO640C-4TN100I	640	1.8V/2.5V/3.3V	74	-4	Lead-Free TQFP	100	IND
LCMXO640C-3MN100I	640	1.8V/2.5V/3.3 V	74	-3	Lead-Free csBGA	100	IND
LCMXO640C-4MN100I	640	1.8V/2.5V/3.3 V	74	-4	Lead-Free csBGA	100	IND
LCMXO640C-3TN144I	640	1.8V/2.5V/3.3 V	113	-3	Lead-Free TOFP	144	IND
LCMXO640C-4TN144	640	1.8V/2.5V/3.3V	113	-4	Lead-Free TQFP	144	IND
LCMXO640C-3MN1321	640	1.8V/2.5V/3.3V	101	-3	Lead-Free csBGA	132	IND
LCMXO640C-4MN1321	640	1.8V/2.5V/3.3V	101	-4	Lead-Free csBGA	132	IND
LCMXO640C-3BN256I	640	1.8V/2.5V/3.3V	159	-3	Lead-Free caBGA	256	IND
LCMXO640C-4BN256I	640	1.8V/2.5V/3.3V	159	-4	Lead-Free caBGA	256	IND
LCMXO640C-3FTN256I	640	1.8V/2.5V/3.3V	159	-3	Lead-Free ftBGA	256	ND
LCMXO640C-4FTN256I	640	1.8V/2.5V/3.3V	159	4	Lead-Free ftBGA	256	IND
LCMXO1200C-3TN100	1200	1.8V/2.5V/3.3 V	73	3	Lead-Free TQFP	100	IND
LCMXO1200C-4TN100I	120	1.8V/2.5V/3.3V	73	-4	Lead-Free TQFP	100	ND
LCMXO1200C-3TN144I	1200	1.8V/2.5V/3.3 V	113	-3	Lead-Free TQFP	144	IND
LCMXO1200C-4TN144I	1200	1.8V/2.5V/3.3 V	113	-4	Lead-Free TQFP	144	IND
LCMXO1200C-3MN1321	120	1.8V/2.5V/3.3V	101	-3	Lead-Free csBGA	132	IND
LCMXO1200C-4MN1321	120	1.8V/2.5V/3.3 V	101	-4	Lead-Free csBGA	132	IND
LCMXO1200C-3BN256I	1200	1.8V/2.5V/3.3V	211	3	Lead-Free caBGA	256	IND
LCMXO1200C-4BN256I	1200	1.8V/2.5V/3.3 V	211	-4	Lead-Free caBGA	256	IND
LCMXO1200C-3FTN256I	1200	1.8V/2.5V/3.3V	211	3	Lead-Free ftBGA	256	IND
LCMXO1200C-4FTN256I	1200	1.8V/2.5V/3.3V	211	-4	Lead-Free ftBGA	256	IND
LCMXO2280C-3TN100I	2280	1.8V/2.5V/3.3 V	73	3	Lead-Free TOFP	100	IND
LCMXO2280C-4TN100I	2280	1.8V/2.5V/3.3V	73	4	Lead-Free TQFP	100	IND
LCMXO2280C-3TN144I	228	1.8V/2.5V/3.3V	113	-3	Lead-Free TOFP	144	IND
LCMXO2280C-4TN1441	228	1.8V/2.5V/3.3V	113	-4	Lead-Free TQFP	144	IND
LCMXO2280C-3MN1321	2280	1.8V/2.5V/3.3V	101	-3	Lead-Free csBGA	132	IND
LCMXO2280C-4MN132	228	1.8V/2.5V/3.3V	101	-4	Lead-Free csBGA	132	IND
LCMXO2280C-3BN256I	228	1.8V/2.5V/3.3V	211	-3	Lead-Free caBGA	256	IND
LCMXO2280C-4BN256I	2280	1.8V/2.5V/3.3V	211	-4	Lead-Free caBGA	256	IND
LCMXO2280C-3FTN256I	2280	1.8V/2.5V/3.3V	211	-3	Lead-Free ftBGA	256	IND
LCMXO2280C-4FTN256I	2280	1.8V/2.5V/3.3V	211	-4	Lead-Free ftBGA	256	IND
LCMXO2280C-3FTN3241	2280	1.8V/2.5V/3.3V	271	-3	Lead-Free ftBGA	324	IND
LCMXO2280C-4FTN3241	2280	1.8V/2.5V/3.3V	271	4	Lead-Free ftBGA	324	IND
LCMXO256E-3TN100	256	1.2V	78	-3	Lead-Free TOFP	100	ND
LCMXO256E-4TN100	256	1.2V	78	-4	Lead-Free TOFP	100	ND
LCMXO256E-3MN100I	256	1.2V	78	-3	Lead-Free csBGA	100	ND
LCMXO256E-4MN100I	256	1.2V	78	-4	Lead-Free csBGA	100	ND
LCMXO640E-3TN100	640	1.2V	74	-3	Lead-Free TQFP	100	ND
LCMXO640E-4TN100	640	1.2V	74	-4	Lead-Free TOFP	100	IND
LCMXO640E-3MN100I	640	1.2V	74	3	Lead-Free csBGA	100	ND
LCMXO640E-4MN100I	640	1.2V	74	-4	Lead-Free csBGA	100	ND

Part Number	LUTs	Supply Voltage	l/Os	Grade	Package	Pins	Temp
LCMXO640E-3TN144I	640	1.2 V	113	3	ead-Free TOFP	144	IND
LCMXO640E-4TN144I	640	1.2 V	113	4	Lead-Free TOFP	144	IND
LCMXO640E-3MN132I	640	1.2V	101	3	ead-Free csBGA	132	IND
LCMXO640E-4MN132I	640	1.2 V	101	4	ead-Free csBGA	132	IND
LCMXO640E-3BN256	640	1.2V	159	3	ead-Free caBGA	256	IND
LCMXO640E-4BN256	640	1.2 V	159	4	Lead-Free caBGA	256	IND
LCMXO640E-3FTN256I	640	1.2 V	159	-3	Lead-Free ftBGA	256	IND
LCMXO640E-4FTN256	640	1.2 V	159	4	ead-Free ftBGA	256	IND
LCMXO1200E-3TN100	1200	1.2 V	73	3	Lead-Free TOFP	100	IND
LCMXO1200E-4TN100	1200	1.2V	73	4	ead-Free TOFP	100	IND
LCMXO1200E-3TN144I	1200	1.2 V	113	3	ead-Free TOFP	144	IND
LCMXO1200E-4TN144I	1200	1.2 V	113	4	ead-Free TOFP	144	IND
LCMXO1200E-3MN132	1200	1.2 V	101	3	ead-Free csBGA	132	IND
LCMXO1200E-4MN1321	1200	1.2 V	101	4	Lead-Free csBGA	132	IND
LCMXO1200E-3BN256I	1200	1.2V	211	3	ead-Free caBGA	256	IND
LCMXO1200E-4BN256I	1200	1.2 V	211	4	ead-Free caBGA	256	IND
LCMXO1200E-3FTN256	1200	1.2V	211	-3	ead-Free ftBGA	256	IND
LCMXO1200E-4FTN256	1200	1.2 V	211	4	ead-Free ftBGA	256	IND
LCMXO2280E-3TN100	2280	1.2V	73	3	ead-Free TOFP	100	IND
LCMXO2280E-4TN100	228	1.2 V	73	4	ead-Free TOFP	100	IND
LCMXO2280E-3TN144I	2280	1.2 V	113	3	Lead-Free TOFP	144	IND
LCMXO2280E-4TN144I	2280	1.2V	113	4	ead-Free TOFP	144	IND
LCMXO2280E-3MN132	2280	1.2 V	101	3	Lead-Free csBGA	132	IND
LCMXO2280E-4MN132	2280	1.2 V	101	4	ead-Free csBGA	132	IND
LCMXO2280E-3BN256I	2280	1.2 V	211	3	Lead-Free caBGA	256	IND
LCMXO2280E-4BN256I	2280	1.2V	211	-4	ead-Free caBGA	256	IND
LCMXO2280E-3FTN256	2280	1.2 V	211	3	ead-Free ftBGA	256	IND
LCMXO2280E-4FTN256	2280	1.2 V	211	4	Lead-Free ftBGA	256	IND
LCMXO2280E-3FTN324I	2280	1.2V	271	3	Lead-Free ftBGA	324	IND
LCMXO2280E-4FTN324I	2280	1.2 V	271	-4	Lead-Free ftBGA	324	IND

1.1. 特性

•非易失性，无限可重构

•即时启动-在微秒内启动

•单芯片，不需要外部配置内存

•出色的设计安全性，无比特流拦截

•在毫秒内重新配置基于SRAM的逻辑

SRAM和非易失性存储器

通过JTAG端口可编程

•支持后台编程的非易失性存储器

•睡眠模式

•允许高达100倍的静态电流减少

TransFR™Reconfiguration (TFR)

•在系统运行时进行现场逻辑更新

•高I/O到逻辑密度

•256至2280 lut4

•73至271 I/ o与广泛的封装选项

•支持密度迁移

•无铅/符合RoHS标准的包装

•嵌入式和分布式内存

•高达27.6 Kbits的systemm™嵌入式块

内存

•高达7.7 Kbits的分布式RAM

•专用FIFO控制逻辑

•灵活的I/O缓冲

•可编程的sysIO™缓冲器支持广泛

接口范围:

lvcmos 3.3/2.5/1.8/1.5/1.2

•LVTTL

•一种总线标准

LVDS，总线LVDS, LVPECL, RSDS

•sysCLOCK™PLLs

•每个设备最多两个模拟锁相环

•时钟乘法，除法和相移

•系统级支持

IEEE标准1149.1边界扫描

•板载振荡器

•设备运行3.3 V, 2.5 V, 1.8 V或1.2V电源

•符合IEEE 1532的系统编程
